NUMERICAL SIMULATION OF A CYLINDRICAL ELECTROSTATIC ANALYZER
-
摘要: 对美国DMSP系列卫星载60°圆柱形分析器的性能进行了数值模拟:以同时过松弛迭代法解Laplace方程,得到分析器内的势分布,由荷电粒子在分析器势场中的运动轨道以及传输概率的MontCarlo积分得出分析器的各种响应和几何因子.变动与分析器几何相联系的输入量,计算机程序可移用于其它圆柱形分析器.Abstract: Numerical simulation is made to SSJ/460°cylindrical electron detector boardedon DMSPsatellites. The potential distribution in the analyzer is found from solvingLaplace equation by means of SORiteration procedure. Based on the numericalsolutions of path equation, the responses of the detector are computed by using MontCarlo method. The appropriate choice of time and energy scale in the simulationleads to simple scaling laws of the response functions and the geometrical factor.
-
Key words:
- Potential field /
- Path /
- Geometrical factor
-
-
