太阳风中磁场重联离子扩散区的大尺度特征

徐晓军; 魏奉思; 冯学尚

doi:10.11728/cjss2012.06.778

太阳风中磁场重联离子扩散区的大尺度特征

doi: 10.11728/cjss2012.06.778

1.
南昌大学空间科学与技术研究院南昌 330031
2.
中国科学院空间科学与应用研究中心空间天气学国家重点实验室北京 100190

基金项目: 国家自然科学基金项目(40890162, 40921063, 40904049和41031066)和国家重点实验室专项基金共同资助

详细信息

中图分类号: P353
计量
- 文章访问数: 2432
- HTML全文浏览量: 17
- PDF下载量: 1053
- 被引次数: 0
出版历程
- 收稿日期: 2011-05-04
- 修回日期: 2011-11-18
- 刊出日期: 2012-11-15

Characteristics of Reconnection Diffusion Region in the Solar Wind

1.
Institute of Space Science and Technology, Nanchang University, Nanchang 330031
2.
State Key Laboratory of Space Weather, Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 利用ACE和WIND卫星2007年1月6日的联合探测, 在1AU附近发现了一个等离子体密度极低的Petschek-like重联喷流区. 该喷流区内部出现了非常明显的Hall双极磁场、等离子体密度下降区以及与Hall电流相符的低能段电子投掷角分布. 这些特征与重联离子扩散区的Hall效应非常吻合, 说明很可能在太阳风中观测到了一个离子扩散区. 分析表明, 与之相关的磁场重联为准稳态快速完全反向重联, 其扩散区以一对慢模波为边界, 空间尺度达到80个离子惯性长度, 表现出了大尺度重联的特征.
- 磁场重联 /
- 离子扩散区 /
- 重联喷流区 /
- Hall效应
Abstract: A Petschek-like reconnection exhaust of extremely low plasma density was detected by ACE and WIND on 6 January 2007 near 1AU in the solar wind. The exhaust is characterized by an apparent Hall bipolar magnetic field, ion and electron density depletion layers and pitch angle distribution of low energy electrons anti-parallel to the direction of Hall current. Such features indicate a possible reconnection ion diffusion region in the solar wind. To the best of our knowledge, this is the first time to report direct detections of ion diffusion region associated with solar wind reconnection exhaust. Observations show that the associated reconnection is quasi-steady, almost anti-parallel merging (no guide field) and fast with a dimensionless reconnection rate of about 2%. Meanwhile, the diffusion region is bounded by a pair of slow-mode waves and the spatial width is up to 80 ion inertial lengths, performing large-scale characteristics of reconnection for large systems.
- Magnetic reconnection /
- Ion diffusion region /
- Reconnection exhaust /
- Hall Effect

HTML全文

参考文献(29)

[1]	Wang Shui, Lee L C. Magnetic Reconnection[M]. Anhui: Anhui Education Press, 1999. In Chinese (王水, 李罗权. 磁场重联. 安徽: 安徽教育出版社, 1999)
[2]	Petschek H E. Magnetic Field Annihilation[M]. NASA Special Publication, 1964
[3]	Priest E, Forbes T. Magnetic Reconnection: MHD Theory and Application[M]. New York: Cambridge University Press, 2000
[4]	Birn J, Hesse M. Geospace Environment Modeling (GEM) magnetic reconnection challenge: Resistive tearing, anisotropic pressure and hall effects[J]. J. Geophys. Res., 2001, 106(A3):3737-3750
[5]	Ma Z W, Lee L C. Hall effects on the generation of field-aligned currents in three-dimensional magnetic reconnection[J]. J. Geophys. Res., 2001, 106(A11):25951-25960
[6]	PritchettPL. Collisionless magnetic reconnection in a three-dimensional open system[J]. J. Geophys. Res., 2001, 106(A11):25961-25978
[7]	Rogers B N, Dento R E, Drake J F, et al. Role of dispersive waves in collisionless magnetic reconnection[J]. Phys. Rev. Lett., 2001, 87, 195004
[8]	Shay M A, Drake J F, Rogers B N, et al. Alfvenic collisionless magnetic reconnection and the Hall term[J]. J. Geophys. Res., 2001, 106:3759-3772
[9]	Vasyliunas V M. Theoretical models of magnetic field line merging. I[J]. Rev. Geophys. Space Phys., 1975, 13:303-336
[10]	Mozer F S, Bale S D, Phan T D. Evidence of diffusion regions at a subsolar magnetopause crossing[J]. Phys. Rev. Lett., 2002, 89, 015002
[11]	Vaivads A, Khotyainstev Y, Andre M, et al. Structure of the magnetic reconnection diffusion region from four spacecraft observations[J]. Phys. Rev. Lett., 2004, 93, 105001
[12]	Oieroset M, Phan T D, Fujimoto M, et al. In situ detection of collisionless reconnection in the Earth's magnetotail[J]. Nature, 2001, 412:414-417
[13]	Wygant J R, Cattell C A, Lysak R, et al. Cluster observations of an intense normal component of the electric field at a thin reconnection current sheet in the tail and its role in the shock-like acceleration of the ion fluid into the separatrix region[J]. J. Geophys. Res., 2005, 110(A09), A09206
[14]	Wei F S, Hu X, Feng X S, et al. Magnetic reconnection phenomena in interplanetary space[J]. Space Sci. Rev., 2003, 107:107-110
[15]	Wei F S, Liu R, Fan Q L, et al. Identification of the magnetic cloud boundary layers[J]. J. Geophys. Res., 2003, 108:1263
[16]	Gosling J T, Skoug R M, McComas D J, et al. Direct evidence for magnetic reconnection in the solar wind near 1AU[J]. J. Geophys. Res., 2005, 110:1107
[17]	Levy P H, Petschek H E, Siscoe G L, et al. Aerodynamic aspects of the magnetospheric flow[J]. AIAA J., 1964, 2(12):2065-2076
[18]	Davis M S, Phan T D, Gosling J T, et al. Detection of oppositely directed reconnection jets in a solar wind current sheet[J]. Geophys. Res. Lett., 2006, 33, L19102.
[19]	Xu X, Wei F, Feng X. Observations of reconnection exhausts associated with large-scale current sheets within a complex ICME at 1AU[J]. J. Geophys. Res., 2011, 116, A05105
[20]	Phan T D, Gosling J T, Davis M S, et al. A magnetic reconnection X-line extending more than 390 Earth radii in the solar wind[J]. Nature, 2006, 439:175-178
[21]	Gosling J T, Eriksson S, Blush L M, et al. Five spacecraft observations of oppositely directed exhaust jets from a magnetic reconnection X-line extending > 4.26km in the solar wind at 1AU[J]. Geophys. Res. Lett., 2007, 34, 20108
[22]	Sonnerup B U O, Cahill Jr L J. Magnetic structure and attitude frome Explorer 12 observations[J]. J. Geophys. Res., 1967, 72:171
[23]	Phan T D, Gosling J T, Davis M S. Prevalence of extended reconnection X-lines in the solar wind at 1AU[J]. Geophys. Res. Lett., 2009, 36:9108
[24]	Yang H A, Hin S P, Zhou G C. Density depletion and Hall effect in magnetic reconnection[J]. J. Geophys. Res., 2006, 111(A11):11223
[25]	Lu Q, Huang C, Xie J L, et al. Features of separatrix regions in magnetic reconnection: comparision of 2-D particle-in-cell simulations and Cluster observations[J]. J. Geophys. Res., 115(A11):208
[26]	Daughton W J, Scudder J, Karimabadi H, et al. Fully kinetic simulations of undriven magnetic reconnection with open boundary conditions[J]. Phys. Plasmas, 2006, 13:72101
[27]	Shay M A, Drake J F, Swisdak M. Two-scale structure of the electron dissipation region during collisionless magnetic reconnection[J]. Phys. Rev. Lett., 2007, 99(15):155002
[28]	Karimabadi H, Daughton W, Scudder J. Mutli-scale structure of the electron diffusion region[J]. Geophys. Res. Lett., 2007, 34(L13):104
[29]	Phan T D, Drake J F, Shay M A, et al. Evidence for an elongated (> 60ion skin depths) electron diffusion region during fast magnetic reconnection[J]. Phys. Rev. Lett., 2007, 99(25):255002
