Simulation of Nequick Parameters of Galileo Satellite Navigation System
-
摘要: 提出了基于IGRF模型的Galileo广播Nequick模型及其参数拟合算法, 解决了Galileo信号仿真中地理场景映射与地磁坐标下的电离层延时修正参数拟合问题. 应用IGRF模型, 可计算出任意给定位置和时间点的地磁参数以及E层、 F1层、F2层的电子密度, 从而计算出Galileo电离层修正参数. 仿真结果表明, 该算法拟合的全球电离层延时与IGS提供的实际观测值基本一致, 仿真精度高于一般的经验电离层模型, 实现了Galileo卫星信号的电离层延时修正参数的精确仿真.Abstract: The simulation model of Galileo ionospheric parameters based on IGRF is proposed to solve the problem that ionospheric parameters estimation is related to geomagnetic coordinates. Using IGRF, the geomagnetic elements of the geomagnetic field and the Electron Density can be computed at a given location and time, sequentially, the ionospheric parameters of Galileo can be calculated. The simulation results show that the ionospheric delay calculated by this model is consistent with the value observed by IGS, and the precision is higher than those by other models, which proves that the high precision simulation of the Galileo ionospheric parameters is realized.
-
Key words:
- Ionospheric error /
- Nequick model /
- Galileo satellite /
- IGRF model
-
[1] Coosson P, Radicella M S, Nava B. Comparisons of experimental topside electron concentration profiles with IRI and NeQuick models[J]. Ann. Geophys., 2002, 45(1):111-116 [2] Wang Jun, Dang Yamin, Xue Shuqiang. Application of a new ionospheric model--NeQuick in China[J]. Sci. Surv. Mapp., 2007, 32(4):38-39. In Chinese (王军, 当亚民, 薛树强. NeQuick电离层模型在中国地区的应用[J]. 测绘科学, 2007, 32(4):38-39) [3] Memarzadeh Y. Ionospheric Modeling for Precise GNSS Applications[D]. Tehran: Science in Geodesy Engineering, K.N. Toosi University of Technology, 2009 [4] Belabbas B, Schlueter S, Sadeque M Z. Impact of NeQuick Correction Model to Positioning and Timing Accuracy using the Instantaneous Pseudo Range Error of Signal Frequency Absolute Positioning Receivers[DB/OL]. 2005-09-13[2011-05-12]. http://elib.dlr.de/19831/01/99415.pdf [5] Aragón-Ángel A, Orus R, Hernández-Pajares M, et al. Preliminary NeQuick assessment for future single frequency users of GALILEO[J/OL]. 2002[2011-05-06]. http://www.isprs.org/publications/related/semana_geo-matica05/front/abstracts/Dimarts8/N04.pdf. [6] Cheng Jianquan, Yang Yuhong, Xin Gang. Computation and application of key input parameters of international reference ionosphere[J]. J. Inf. Eng. Univ., 2011, 12(1):56-57. In Chinese (程建全, 杨育红, 辛刚. 国际参考电离层 关键输入参数计算及应用[J]. 信息工程大学学报, 2011, 12(1):56-57) [7] European Union. European GNSS (Galileo) Open Service Signal In Space Interface Control Document[R], OS SIS ICD, 2010. 49 [8] Wang Jiexian, Li Haojun. Calculation and formula deduction of magnetic Declination and geomagnetic inclination[J]. J. Geod. Geodyn., 2009, 29(3):89. In Chinese (王解先, 李浩军. 磁偏角与磁倾角 的公式推导与运算[J]. 大地测量与地球动力学, 2009, 29(3):89)
