环境C卫星热系统设计与在轨验证

王磊; 文耀普

doi:10.11728/cjss2015.02.224

环境C卫星热系统设计与在轨验证

doi: 10.11728/cjss2015.02.224

王磊,
文耀普

中国空间技术研究院钱学森空间技术实验室北京 100094

基金项目: 国家重大科技专项工程项目资助

详细信息

中图分类号: V474.2;TK124
计量
- 文章访问数: 1352
- HTML全文浏览量: 66
- PDF下载量: 1285
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-21
- 修回日期: 2015-01-03
- 刊出日期: 2015-03-15

Thermal design and flight validation of HJ-1-C

Wang Lei,
Wen Yaopu

Qian Xuesen Laboratory of Space Technology, China Academy of Space Technology, Beijing 100094

摘要

摘要: 根据环境C卫星的自身特性, 采用以被动式热控制为主和主动热控制为辅的控制方式, 对环境C卫星进行热系统设计. 通过研究环境C卫星的热控设计原则、热设计状态及已解决的关键问题, 对其在轨飞行温度数据进行了分析. 在轨飞行遥测结果表明, 环境C卫星热控系统方案合理, 工作稳定, 性能良好. 星上设备温度环境很好地满足了设计要求.
- 遥感航天器 /
- 热设计 /
- 飞行验证
Abstract: HJ-1-C is a Synthetic Aperture Radar (SAR) satellite of the Chinese Environment and Natural Disaster Monitoring constellation launched on November 19, 2012. The SAR payload uses mesh parabolic reflector antenna and solid-state transmitter to transmit high power in centralized manner. Based on the design concept that passive thermal control would be preferred over active thermal control for its simplicity and inherent reliability, HJ-1-C satellite thermal control system were provided in accordance with the HJ-1-C satellite working characteristics and space thermal environment on its orbit. The presentations about thermal design techniques, scheme and key problems solved are given. Moreover, onboard performance of the satellite on its orbit was analyzed. The flight telemetry data showed that the thermal control design was reasonable and well satisfied with the temperature requirements of the electronic equipments and payloads, which ensured the safety and reliability operation of satellite.
- Remote sensing spacecraft /
- Thermal design /
- Flight Validation

HTML全文

参考文献(11)

[1]	Wei Zhongquan. Synthetic Aperture Radar satellite[M]. Beijing: Science Press, 2001. In Chinese (魏钟铨. 合成孔径雷达卫星[M]. 北京: 科学出版社, 2001)
[2]	Deng Yunkai, Zhao Fengjun, Wang Yu. Brief analysis on the development and application of spaceborne SAR[J]. J. Radars, 2012, 1(1):1-10. In Chinese (邓云凯, 赵凤军, 王宇. 星载SAR技术的发展趋势及其应用浅析[J]. 雷达学报, 2012, 1(1):1-10)
[3]	Rajagopalan H, Miura A, Rahmat S Y. Equivalent strip width for cylindrical wire for mesh reflector antennas: experiments, waveguide, and plane-wave simulations[J]. IEEE Trans. Antenn. Propag., 2006, 54(10):2845-2853
[4]	Abdelal G F, Abuelfoutouh N, Hamdy A, et al. Thermal fatigue analysis of small-satellite structure[J]. Intern. J. Mech. Mater. Design, 2006, 3(2):145-159
[5]	Gilmore D G. Spacecraft Thermal Control Handbook[M]. El Segundo, California: Aerospace Press, 2002
[6]	Anderson B J, Justus C G, Batts W. Guidelines for the Selection of Near-Earth Thermal Environment Parameters for Spacecraft Design[R]. Alabama: NASA, 2001
[7]	Xu Xianghua, Cheng Xuetao, Liang Xingang. Analysis on space thermal environment for circular Sun-synchronous orbit[J]. J. Astron., 2012, 33(3):399-404. In Chinese (徐向华, 程雪涛, 梁新刚. 圆形太阳同步轨道卫星的空间热环境分析[J]. 宇航学报, 2012, 33(3):399-404)
[8]	Min Guirong, Guo Shun. Satellite Thermal Control Technology[M]. Beijing: Science Press, 1998. In Chinese (闵桂荣, 郭舜. 航天器热控制[M]. 北京: 科学出版社, 1998)
[9]	Luke M, Masud B, Graham M. Systematic evaluation of thermal interface materials——A case study in high power amplifier design[J]. Microelectr. Reliab., 2005, 45(3/4):711-725
[10]	Wang Lei, Wen Yaopu. Thermal design and test for power amplifier[J]. Spacecr. Eng., 2012, 20(2):52-56. In Chinese (王磊, 文耀普. 一种微波功率放大器的热设计与验证方法[J]. 航天器工程, 2012, 20(2):52-56)
[11]	Tizzi S. Numerical procedures for thermal problems of space antennae shells[J]. Acta Astron., 2004, 54(2):103-114
