微重力燃烧实验火焰结构显示和全场温度测量的原理样机

王静; 孙志斌; 代斌; 戴国亮; 孔黎明; 王宝瑞

doi:10.11728/cjss2015.03.336

微重力燃烧实验火焰结构显示和全场温度测量的原理样机

doi: 10.11728/cjss2015.03.336

1.
扬州大学化学化工学院扬州 225009
2.
中国科学院力学研究所中国科学院微重力重点实验室北京 100190
3.
中国科学院空间科学与应用研究中心北京 100190
4.
中国科学院工程热物理研究所北京 100190

基金项目: 中国科学院空间科学战略性先导科技专项“空间科学预先研究项目”资助(XDA04073200)

详细信息

中图分类号: V524
计量
- 文章访问数: 1055
- HTML全文浏览量: 44
- PDF下载量: 2029
- 被引次数: 0
出版历程
- 收稿日期: 2014-06-18
- 修回日期: 2015-01-04
- 刊出日期: 2015-05-15

Prototype System Used for Flame Structure Display and Temperature Measurement Technology in Microgravity Combustion Experiment

1.
College of Chemistry and Chemical Engineering, Yangzhou University, Yangzhou 225009
2.
Key Laboratory of Microgravity, Institute of Mechanics, Chinese Academy of Sciences, Beijing 100190
3.
Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190
4.
Institute of Engineering Thermophysics, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 用于空间燃烧实验的设备要求轻重量、小尺寸和多功能. 将纹影法、彩虹纹影偏折法与差分干涉法相结合, 研制了可用于火焰结构显示和全场温度测量的原理样机. 该原理样机具有重量轻、尺寸小、模块化和多功能等特点. 通过微重力落塔实验, 检验了利用纹影法测量火焰结构的功能, 同时在常重力条件下检验了利用彩虹纹影偏折法和差分干涉法测量火焰全场温度的功能. 结果表明, 火焰结构分辨率不低于1mm, 火焰温度测量结果精确, 相对误差小于2%. 该原理样机将提升空间燃烧的观察方法, 有助于未来空间燃烧实验的开展.
- 微重力 /
- 火焰结构 /
- 火焰温度场 /
- 原理样机
Abstract: The facility for combustion experiments in space is lightweight, small sized and multi-functional. In this paper, a prototype system used for flame structure display and temperature measurement is presented, which combined the schlieren method, rainbow schlieren deflection method and differential interference method. It is also lightweight and small sized. As for the prototype system, the flame structure display function was checked by schlieren method in microgravity drop tower, and the temperature measurement function was checked by rainbow schlieren deflection and differential interference method under normal gravity condition. Results show that the resolution of flame structure was not less than 1mm, and temperature field measurement was accurate with relative error smaller than 2%. Such prototype system is important to the promotion of space combustion science experiment technology and will be beneficial to the future combustion experiments in space.
- Microgravity /
- Flame structure /
- Flame temperature /
- Prototype system

HTML全文

参考文献(10)

[1]	Kostiuk L W, Cheng R K. Imaging of premixed flames in microgravity[J]. Exp. Fluids, 1994, 18(1/2):59-68
[2]	Kobayashi H, Park J, Iwahashi T, et al. Microgravity experiments on flame spread of an n-decane droplet array in a high-pressure environment[J]. Proc. Combust. Inst., 2002, 29(2):2603-2610
[3]	Li Q, Gu Y X, Dahm W, et al. Near-limit laminar burning velocities of microgravity premixed hydrogen flames with chemically-passive fire suppressants[J]. Proc. Combust. Inst., 2007, 31(2):2701-2709
[4]	Wang S F, Zhang H, Jarosinski J, et al. Laminar burning velocities and Markstein lengths of premixed methane/air flames near the lean flammability limit in microgravity[J]. Combust. Flame, 2010, 157(4):667-675
[5]	Pu Y K, Hu J, Jarosinski J. Experimentally determined flame properties near flammability limits under gravity and microgravity conditions[J]. Combust. Sci. Tech., 2009, 181(12):1431-1442
[6]	Du Wenfeng, Zhang Xiaoqian, Wei Minggang, et al. The Candle flames in microgravity[J]. J. Eng. Thermophys., 2000, 21(4):515-519. In Chinese (杜文锋, 张孝谦, 韦明罡, 等. 微重力环境中的蜡烛火焰[J]. 工程热物理学报, 2000, 21(4):515-519)
[7]	Du Wenfeng, Zhang Xiaoqian, Wei Minggang, et al. Candle flame temperature measurement in microgravity by differential interferometry[J]. J. Combust. Sci. Tech., 2000, 6(2):129-132. In Chinese (杜文锋, 张孝谦, 韦明罡, 等. 差分干涉法测量微重力环境蜡烛火焰的温度[J]. 燃烧科学与技术, 2000, 6(2):129-132)
[8]	Falfonso F I, Chih J S, Hirasawa T, et al. Burning velocity measurements of microgravity spherical sooting premixed flames using rainbow SCHLIEREN deflectiometry[J]. Combust. Flame, 2005, 140(1/2):93-102
[9]	Candes E, Romberg J. Quantitative robust uncertainty principles and optimally sparse decompositions[J]. Found. Comput. Math., 2006, 6(2):227-254
[10]	Jiang Guanlei, Hong Yanji, Ye Jifei, et al. Experimental Investigation of the quantitative measurement by rainbow schlieren[J]. J. Acad. Equip. Comm. Technol., 2012, 23(1):127-131. In Chinese (蒋冠雷, 洪延姬, 叶继飞, 等. 彩虹纹影定量测量实验方法研[J]. 装备指挥技术学院学报, 2012, 23(1):127-131)
