Study on High Precise and High Dynamic Star Simulator
-
摘要: 给出了高精度高动态星模拟器系统组成和总体结构, 提出一种基于亚像素显示技术提高动态星模拟器星点位置显示精度从而减小星点几何中心与能量中心位置偏差的新方法. 针对动态星模拟器高动态性要求, 提出一种快速精确检索全天球导航星的新方法, 将已知SAO (Smithsonian Astrophysical Observatory) 星表进行分区, 计算当前姿态四元数并分析航天器视轴所在区域, 对于距离视轴较远区域停止搜索和匹配, 很大程度上缩小了导航星搜索范围, 进而缩短了全天球恒星遍历所需时间. 软件测试结果表明, 此快速检索法可使全天球导航星的选取速度提高近10倍.
-
关键词:
- 高精度高动态星模拟器 /
- 亚像素显示 /
- 星表分区 /
- 跟踪算法
Abstract: The composition and overall structure of high precise and high dynamic star simulator system is presented, and a new method is put forward based on sub-pixel display technology to improve the dynamic star simulator to display the star point more precisely, which can reduce the position deviations of both geometric center and the energy center of the star point. Meanwhile, a new method for fast and accurate retrieval of the navigational star in the entire celestial sphere is presented by partitioning the SAO (Smithsonian Astrophysical Observatory) star catalogue, analyzing the four elements of the spacecraft attitude to determine where the visual axis points to, eliminating the search and match of navigational stars far from the visual axis so as to reduce the search area, hence decreasing the time that the whole celestial stars traversal required. Through simulation testing, results show that the speed of this quick search method to select the celestial navigational star has been increased by nearly 10 times. -
[1] Lü Zhiqiang. Design of communication and display system of dynamic star simulator based on virtual instrument[D]. Beijing: Beijing Institute of Control Engineering, 2012. In Chinese (吕志强. 基于虚拟仪器的动态星模拟器通讯及显示系统设计[D]. 北京: 北京控制工程研究所, 2012) [2] Chen Yuanzhi, Hao Zhihang, Wang Guohui, et al. Constitution of guide star catalog for star sensor[J]. Opt. Prec. Eng., 2002, 27(5):5-10. In Chinese (陈元枝, 郝志航, 王国辉, 等. 适用于星敏感器的导航星星库制定[J]. 光学精密工程, 2002, 27(5):5-10) [3] Xu Shiwen, Long Funian, Fu Ling, et al. Coordinate transformation in real-time star field simulator[J]. J. Harbin Inst. Tech., 1998, 30(5):118-120. In Chinese (许世文, 龙夫年, 付苓, 等. 实时星场模拟器中的坐标变换[J]. 哈尔滨工业大学学报, 1998, 30(5):118-120) [4] Jiang Jie. A fast star tracking method in star sensor[J]. J. Beijing Univ. Aeron. Astron., 2006, 32(8):878-880. In Chinese (江洁. 星敏感器中快速星跟踪技术[J]. 北京航空航天大学学报, 2006, 32(8):878-880) [5] Hu Yining. Study on Mini-dynamic Star Simulator Technologies[D]. Beijing: University of Chinese Academy of Sciences, 2010. In Chinese (胡宜宁. 小型动态星模拟器技术研究[D]. 北京: 中国科学院大学, 2010)
