External Heat Flux of the Solar Array on the Polar Lunar Orbit
-
摘要: 准确的月球表面温度分布模型对于开展月球探测具有重要意义. 目前有关月球表面温 度模型还缺乏对完整月球表面温度分布的计算方法研究. 本文建立了一套计算完整月球表面温度的方法, 其中月球阳面温度采用Racca模型直接计算得到; 对于月球阴面, 将其沿纬度方向划分为若干区域, 每个区域的地表土壤采用一维非稳态热传导模型, 根据嫦娥三号着陆器太阳电池阵在轨环月阶段的温度数据, 修正得到月球表面土壤导热系数、密度及比热容, 通过数值计算求解一维非稳态热传导方程, 得出任意时刻月球阴面表面温度随时间的变化. 嫦娥三号着陆器太阳电池阵环月阶段热分析结果与在轨温度符合较好, 初步说明本文建立的完整月球表面温度计算方法正确可行. 基于本文方法计算得到整个月球表面温度分布, 进一步研究了极月轨道太阳电池阵外热流变化规律.Abstract: Accurate lunar surface temperature distribution model is important for human lunar exploration. But there is a lack of research on how to calculate the temperature distribution of the entire lunar surface. In this paper, an entire lunar surface temperature model has been established which uses Racca model to calculate temperature of the lunar sunny side. For lunar shady side, the lunar surface is divided into several zones along the latitudinal direction whose temperature is solved by one-dimensional non-steady heat conduction equation. According to Chang'E-3 solar array temperature data, parameter values of the heat conduction equation are amended. Thermal analysis results of Chang'E-3 solar array temperature are in good agreement with the measuring data, which preliminary proves that this model is sound and feasible. Based on lunar temperature distribution calculated by this model, heat flux characteristic of the solar array on polar lunar orbit has been researched.
-
Key words:
- Lunar surface temperature /
- Solar array /
- Polar lunar orbit
-
[1] Ouyang Ziyuan. Introduction to Lunar Science[M]. Beijing: China Astronautic Publishing House, 2005. In Chinese (欧阳自远. 月球科学概论[M]. 北京: 中国宇航出版社, 2005) [2] Zhang Jiaxun, Wen Yaopu, Li Jindong. The Preliminary thermal analysis and thermal control design for polar orbit lunar satellites with solar panels in single degree of freedom[J]. Chin. J. Space Sci., 2004, 24(1):51-57. In Chinese (张加讯, 文耀普, 李劲东. 单自由度太阳帆板极月轨道月球卫星的初步热分析与热设计[J]. 空间科学学报, 2004, 24(1):51-57) [3] Xu Lin, Liu Jianzhong, Zhou Yongliao. Discovery of water ice on the moon surface and its significance[J]. Chin. J. Space Sci., 2003(01):42-49. In Chinese (徐琳, 刘建忠, 邹永廖. 月球表面水冰的探测和意义[J]. 空间科学学报, 2003(01):42-49) [4] Pettit E, Nicholson S B. Lunar radiation and temperatures[J]. J. Astrophys., 1930, 71:102-135 [5] Lawson S L, Jackoksy B M, Hye-Sook Park, et al. Brightness temperatures of the lunar surface: Calibration and global analysis of the clementine long-wave infrared camera data[J]. J. Geophys. Res., 2003, 105(E2):4273-4290 [6] Racca G D. Moon surface thermal characteristics for moon orbiting spacecraft thermal analysis[J]. Planet. Space Sci., 1995, 43(6):835-842 [7] Xu Xianghua, Liang Xingang, Ren Jianxun. Numerical analysis of thermal environment of lunar surface[J]. J. Astronaut., 2006, V27(2):153-156. In Chinese (徐向华, 梁新刚, 任建勋. 月球表面热环境数值分析[J]. 宇航学报, 2006, V27(2):153-156 [8] Liao Yi. Lunar Surface Temperature Distribution of Physical and Numerical Model[D]. Wuhan: Huazhong University of Science and Technology, 2011. In Chinese (廖翼. 月球表面物理温度分布模型及数值计算[D]. 武汉: 华中科技大学, 2011) [9] Fa Wenzhe, Jin Yaqiu. Inversion of lunar regolith layer thickness using microwave radiance simulation of three layer model and Clementine UV-VIS data[J]. Chin. J. Space Sci., 2007, 27(1):55-65. In Chinese (法文哲, 金亚秋. 月球表面多通道辐射亮度温度的模拟与月壤厚度的反演[J]. 空间科学学报, 2007, 27(1):55-65) [10] Ran Zhen, Wang Zhenzhan, Li Yun. Comparison between Diviner data and CELMS data[J]. Chin. J. Space Sci., 2014, 34(3):249-261. In Chinese (冉真, 王振占, 李芸. Diviner红外温度与嫦娥卫星微波探测仪月表亮温的比较分析[J]. 空间科学学报, 2014, 34(3):249-261) [11] Yu wen, Li Xiongyao, Wang Shijie. Effect of thermal environment on lunar exploration: A review[J]. Adv. Earth Sci., 2012, 27(12):1337-1343. In Chinese (于雯, 李雄耀, 王世杰. 月球探测中月面热环境影响的研究现状[J]. 地球科学进展, 2012, 27(12):1337-1343) [12] Li Xiongyao, Wang Shijie, Cheng Anyun. A lunar surface effective solar irradiance real-time model[J]. Chin. J. Geophys., 2008, 51(1):25-30. In Chinese (李雄耀, 王世杰, 程安云. 月表有效太阳辐照度实时模型[J]. 地球物理学报, 2008, 51(1):25-30)
