Ground Measurement and Signal Estimation for Micro-vibration of Quantum Science Experimental Satelliteormalsize
-
摘要:
介绍了卫星微振动地面测试和信号估计方法.根据量子科学实验卫星特点,对动量轮运行状态下光学载荷的微振动线位移及角位移进行估计.通过地面微振动测试系统,测量了动量轮运行下光学载荷的微振动加速度;应用小波积分方法,精确估计了卫星结构敏感点的振动线位移和振动角位移.通过工程实测证明了微振动测试与估计方法的有效性.研究结果对于高精度科学实验卫星微振动地面试验具有一定工程应用意义.
Abstract:In this paper, micro-vibration measurement and signal estimation on the Quantum Science Experimental Satellite ground test is introduced. Based on the technology requirement of the satellite, the method of measurement is determined to detect the vibration of high-accuracy optical payloads when the oscillation source comes from on-board rotatable instruments, such as reaction wheel installed in the satellite body. The characteristics of vibration transfer from a vibration source to sensitive points are estimated, and vibration displacement and angular oscillation are approximated by applying an integration wavelet. The validation of the proposed method is confirmed by experimental test, and the result is of interest in ground test of micro-vibration for Quantum Science Experimental satellite with high accuracy payloads.
-
[1] ZHOU Xiaoxiang, CHEN Erkui, LÜ Guiqing, et al. The processing of vibration acceleration signal based on numeric integration and LMS[J]. Process Autom. Instrum., 2006, 27 (9):51-53(周小祥, 陈尔奎, 吕桂庆, 等. 基于数字积分和LMS的振动加速度信号处理[J]. 自动化仪表, 2006, 27 (9):51-53) [2] LIU Jicheng, XU Qinghua, CHA Jianxin. Method of vibration displacement measured with acceleration sensor[J]. Mod. Radar, 2007, 29 (5):69-71(刘继承, 徐庆华, 查建新. 用加速度传感器测量振动位移的方法[J]. 现代雷达, 2007, 29 (5):69-71) [3] HU Yumei, ZHOU Yingjie, ZHU Hao, et al. Integration algorithm based on trend-control of error in frequency domain[J]. J. Vibrat. Shock, 2015, 34 (2):171-175(胡玉梅, 周英杰, 朱浩, 等. 基于趋势项误差控制的频域积分算法研究与应用[J]. 振动与冲击, 2015, 34 (2):171-175) [4] SMYTH A, WU Meiliang. Multi-rate Kalman filtering for the data fusion of displacement and acceleration response measurements in dynamic system monitoring[J]. Mech. Syst. Sign. Process., 2007, 21 (2):706-723 [5] HUANG Dishan, DU Jicheng, ZHANG Lin, et al. A wavelet-based algorithm for numerical integration on vibration acceleration measurement data[J]. J. Viboeng., 2014, 16 (7):3467-3479
