北极69&#176;N和78&#176;N空间碎片凝视探测的对比分析

唐志美; 丁宗华; 代连东; 吴健; 许正文

doi:10.11728/cjss2018.01.073

北极69°N和78°N空间碎片凝视探测的对比分析

doi: 10.11728/cjss2018.01.073

中国电波传播研究所电波环境特性及模化技术重点实验室青岛 266107

详细信息

作者简介:
唐志美,E-mail:1248765010@qq.com

中图分类号: V412
计量
- 文章访问数: 1235
- HTML全文浏览量: 46
- PDF下载量: 801
- 被引次数: 0
出版历程
- 收稿日期: 2017-02-22
- 修回日期: 2017-05-02
- 刊出日期: 2018-01-15

Comparative Analysis of Space Debris Gaze Detection Based on Two Incoherent Scattering Radars Located at 69°N and 78°N ormalsize

National Key Laboratory of Electro-Magnetic Environment, China Research Institute of Radiowave Propagation, Qingdao 266107

摘要

摘要: 利用北极69°N和78°N两套非相干散射雷达的首次空间碎片联合观测数据进行空间碎片参数（距离、速度、散射截面积、等效直径等）的对比分析，得出以下结论：两部雷达探测的碎片高度均主要分布在500～1100km和1400～1600km区间，但78°N雷达探测的碎片数量较多；空间碎片的径向速度均在-1.5～1.5km…^-1区间，其中大部分为负值，说明在此次探测试验中碎片运动方向主要以远离雷达或地球为主；ESR雷达探测的空间碎片射截面积约为10^-5～10^-2m²，等效直径主要分布在4～10cm，而UHF雷达探测的空间碎片散射截面积约为10^-6～10^-2m²，等效直径主要分布在2～6cm，说明在同一高度上69°N雷达探测能力更强；经合理设置判据参数后得出重复检测次数，78°N雷达和69°N雷达分别有32次和14次重复检测，两部雷达共有4次重复检测.这些结果为空间碎片检测和建模提供了参考.
- 非相干散射雷达 /
- 空间碎片 /
- 参数 /
- 统计分布
Abstract: Based on the joint observation of two incoherent scattering radars located at 69°N and 78°N, parameters including the height, radial velocity, Radar Cross-section, and effective diameter etc. are obtained. Statistical analysis on these data is made and conclusions are drawn as follows. The space debris detected by the two radars are distributed at the height from 500 to 1100km and from 1400 to 1600km, but the number of pieces detected by the radar located at 78°N is more than that detected by the radar at 69°N. The radial velocities are almost distributed in -1.5~1.5km…^-1 and more of them are negative, which shows that most of the debris move far away from the Earth in this detection. The RCS is about 10^-5~10^-2m² and the effective diameter is about 3~10cm at 69°N, and the RCS is about 10^-6~10^-2m² and the effective diameter is about 2~6cm at 78°N. The minimum size of space debris detected by the radar located at 78°N is bigger than the one detected by the radar at 69°N, which means that the detection power of the radar located at 69°N is stronger than the radar at 78°N at the same height. Concluding the repeat testing number after setting up reasonable criterion parameters, the two radars located at 69°N and 78°N respectively have 32 and 14 repeat numbers, and 4 repeat numbers overlapped. These results show the good perspective in the fragment cataloging and modeling of the space debris.
- Incoherent Scatter Radar /
- Space debris /
- Parameter /
- Statistical distribution

HTML全文

参考文献(12)

[1]	SATO T, WAKAYAMA, TANAKA T, et al. Shape of space debris as estimated from radar cross section variations[J]. J. Space. Rockets, 1994, 31(4):665-670
[2]	MARKKANEN J, LENHTINEN M, LANDGRAF M. Real time space debris monitoring with EISCAT[J]. Adv. Space Res., 2005, 35(7):1197-1209
[3]	MARKKANEN J, POSTILA M. Real-Time Small-Size Space Debris Detection with EISCAT Radar Facilities[R]. Kiruna: EISCAT the European Incoherent Scatter Scientific Association, 2005
[4]	MARKKANEN J, POSTILA M, VAN EYKEN A. Small-Size Space Debris Data Collection with EISCAT Radar Facilities[R]. Kiruna: EISCAT the European Incoherent Scatter Scientific Association, 2006
[5]	MARKKANEN J. EISCAT Space Debris Measurements 2006[R]. Kiruna: EISCAT the European Incoherent Scatter Scientific Association, 2006
[6]	JIN Wang, WU Zhensen, WU Jian, et al. Space debris experimentation study using incoherent scatter radar[J]. Chin. J. Radio Sci., 2011, 26(5):956-960 (金旺, 吴振森, 吴健, 等. 非相干散射雷达探测空间碎片实验研究[J]. 电波科学学报, 2011, 26(5):956-960)
[7]	LIU Yongjun, GE Debiao, JIN Wang. Match function method for space debris detection using incoherent scatter radar measurement[J]. Chin. J. Radio Sci., 2012, 32(1):60-67 (刘拥军, 葛德彪, 金旺. 匹配滤波方法在非相干散射雷达测量空间碎片中的应用[J]. 空间科学学报, 2012, 32(1):60-67)
[8]	DING Zonghua, XU Zhengwen, ZHAO Zhenwei. Parameter extraction of space debris by the incoherent scattering radar[J]. Modern Radar, 2014, 36(2):1-9 (丁宗华, 许正文, 赵振维. 非相干散射雷达的空间碎片参数提取[J]. 现代雷达, 2014, 36(2):1-9)
[9]	(丁宗华, 代连东, 赵振维, 等. 非相干散射雷达的空间碎片信号处理与分析[J]. 电波科学学报, 2014, 29(3):417-423) DING Zonghua, DAI Liandong, ZHAO Zhenwei, et al. Space debris's signal processing and analysis based on the incoherent scatter radar [J]. Chin. J. Radio Sci., 2014, 29(3):417-423)
[10]	DAI Liandong, DING Zonghua, ZHAO Zhenwei, et al. Statistical analysis of space debris's parameters based on the incoherent scattering radar[J]. Chin. J. Space Sci., 2015, 35(4):495-501 (代连东, 丁宗华, 赵振维, 等. 非相干散射雷达的空间碎片参数统计分析[J]. 空间科学学报, 2015, 35(4):495-501)
[11]	LI Chunlai, OUYANG Ziyuan, DU Heng. Space debris and space environment[J]. Quat. Sci., 2002, 22(6):540-550 (李春来, 欧阳自远, 都亨. 空间碎片与空间环境[J]. 第四纪研究, 2002, 22(6):540-550)
[12]	DING Zonghua, DAI Liandong, FU Tuo, et al. The preliminary results of the space debris observation by the Qujing incoherent scatter radar[C]//The 8th National Space Debris Academic Exchange Meeting. Beijing: National Space Debris Monitoring and Application Center, 2015:26-33 (丁宗华, 代连东, 付佗, 等. 曲靖非相干散射雷达的空间碎片初步探测结果[C]//第八届全国空间碎片学术交流会. 北京: 国家航天局空间碎片监测与应用中心, 2015:26-33)
