Characteristics of Wind and Planetary Waves Based on FPI over Kelan of Chinaormalsize
-
摘要: 利用中国岢岚站(38.7°N,111.6°W)法布里-珀罗干涉仪2013年7月至2014年11月的水平风场数据,对87,97,250km风场长期变化和行星波特征进行了研究.通过分析年振荡(AO)和半年振荡(SAO)振幅相位,将午夜风场与HWM07数据对比发现:87km和97km处FPI纬向风变化趋势与HWM07相近,而经向风相位落后于HWM07,从振幅上看,HWM07振幅偏大;250km处风场月变化大,FPI与HWM07差异大,HWM07模式的准确性需进一步考虑太阳活动和行星际磁场的影响.利用Lomb-Scargle功率谱以及最小二乘谐波拟合提取了三个高度的行星波振幅,其特征表明87km和97km处纬向风16日波秋季及冬春季活动强,而6.5日波最强振幅出现在春季和秋季,在中间层顶附近两种行星波活动均较弱;250km处经向行星波活动略强于纬向,经向风不同周期带的行星波最强振幅主要出现在5-9月,与电离层f0F2振荡特性的研究结果一致.Abstract: The horizontal wind data observed by Fabry-Perot Interferometer (FPI) over Kelan, China, has been used to investigate the characteristics of wind and planetary waves at altitudes of 87, 97 and 250km. Firstly, the midnight winds have been compared with those from HWM07. The results are as follows. At 87 and 97km, the AO (Annual Oscillation) and SAO (Semiannual Oscillation) phases of zonal wind of FPI tend to consist with those from HWM07, while the phases of FPI meridional wind lag behind. Both the zonal and meridional FPI amplitudes are smaller. It shows large discrepancies between FPI and HWM07 winds, which reveals that the improvement of HWM07 model needs to further consider the influence of solar activity and interplanetary magnetic field. Secondly, the Lomb-Scargle analysis and the least squares harmonic fitting method have been used to derive the amplitudes of planetary waves at the three altitudes. At 87 and 97km, the 16-day waves are prominent at autumn, winter and spring during 2013-2014, while the 6.5-day waves tend to dominant spring and autumn. Both of the two planetary waves have weak amplitudes around mesopause. The amplitudes are stronger in meridional wind than zonal at 250km. Three typical planetary wave period bands of meridional wind show that the strongest amplitudes persist from May to October. This is consist with the results of ionospheric f0F2 oscillations.
-
Key words:
- Fabry-Perot Interferometer /
- Wind feature /
- Planetary waves
-
[1] KAWAMURA S, OTSUKA Y, ZHANG S R, et al. A climatology of middle and upper atmosphere radar observations of thermospheric winds[J]. J. Geophys. Res., 2000, 105(A6):12777-12788 [2] BIONDI M A, SAZYKIN S Y, FEJER B G, et al. Equatorial and low latitude thermospheric winds:measured quiet time variations with season and solar flux from 1980 to 1990[J]. J. Geophys. Res., 1999, 104(A8):17091-17106 [3] XIONG J G, WAN W, NING B, et al. First results of the tidal structure in the MLT revealed by Wuhan Meteor Radar (30°40'N, 114°30'E)[J]. J. Atmos. Sol.-Terr. Phys., 2004, 66(6-9):675-682 [4] MANSON A H, MEEK C E. Characteristics of gravity waves (10min-6 hours) at Saskatoon (52°N, 107°W):observations by the phase coherent medium frequency radar[J]. J. Geophys. Res., 1993, 98(D11):20357-20367 [5] SALAH J E, HOLT J M. Midlatitude thermospheric winds from incoherent scatter radar and theory[J]. Radio Sci., 1974, 9(2):301-313 [6] YU Tao, HUANG Cong, ZHAO Guangxin, et al. A preliminary study of thermosphere and mesosphere wind observed by Fabry-Perot over Kelan, China[J]. J. Geophys. Res., 2014, 119(6):4981-4997 [7] DROB D P, EMMERT J T, CROWLEY G, et al. An empirical model of the Earth's horizontal wind fields:HWM07[J]. J. Geophys. Res., 2008, 113(A12):A12304 [8] EMMERT J T, FEJER B G, SHEPHERD G G, et al. Altitude dependence of middle and low-latitude daytime thermospheric disturbance winds measured by WINDⅡ[J]. J. Geophys. Res., 2002, 107(A12):1483 [9] WON Y I, SIVJEE G G, AZEEM S M I, et al. Tidal features in the wintertime mesospheric temperature and neutral winds recorded at Resolute Bay, Canada (74.68°N, 94.90°W)[J]. J. Atmos. Sol.-Terr. Phys., 2007, 69(4-5):459-470 [10] WU Q, GABLEHOUSE R D, KILLEEN T L, et al. Multi-year high latitude mesospheric neutral wind observations using a Fabry-Perot interferometer[J]. Adv. Space Res., 2005, 35(11):1895-1899 [11] TANG Lei, HUANG Chunming. Mid-latitude planetary waves observation from MST radar measurements in the troposphere and lower stratosphere[J]. Chin. J. Space Sci., 2016, 36(2):175-187(汤蕾, 黄春明. 基于MST雷达数据的中纬对流层和低平流层大气行星波研究[J]. 空间科学学报, 2016, 36(2):175-187) [12] HUANG Y Y, ZHANG S D, YI F, et al. Global climatological variability of quasi-two-day waves revealed by TIMED/SABER observations[J]. Ann. Geophys., 2013, 31(6):1061-1075 [13] FORBES J M, HAGAN M E, MIYAHARA S, et al. Quasi 16-day oscillation in the mesosphere and lower thermosphere[J]. J. Geophys. Res., 1995, 100(D5):9149-9163 [14] DAY K A, HIBBINS R E, MITCHELL N J. Aura MLS observations of the westward-propagating s!=!1, 16-day planetary wave in the stratosphere, mesosphere and lower thermosphere[J]. Atmos. Chem. Phys., 2011, 11(9):4149-4161 [15] CHARNEY J G, DRAZIN P G. Propagation of planetaryscale disturbances from the lower into the upper atmosphere[J]. J. Geophys. Res., 1961, 66(1):83-109 [16] LUO Yi, MANSON A H, MEEK C E, et al. The quasi 16-day oscillations in the mesosphere and lower thermosphere at Saskatoon (52°N, 107°W), 1980-1996[J]. J. Geophys. Res., 2000, 105(D2):2125-2138 [17] HOLTON J R. The generation of mesospheric planetary waves by zonally asymmetric gravity wave breaking[J]. J. Atmos. Sci., 1984, 41(23):3427-3430 [18] JIANG G, XIONG J, WAN W, et al. Observation of 6.5-day waves in the MLT region over Wuhan[J]. J. Atmos. Sol.-Terr. Phys., 2008, 70(1):41-48 [19] RIGGIN D M, LIU H L, LIEBERMAN R S, et al. Observations of the 5-day wave in the mesosphere and lower thermosphere[J]. J. Atmos. Sol.-Terr. Phys., 2006, 68(3-5):323-339 [20] MEYER C K, FORBES J M. A 6.5-day westward propagating planetary wave:Origin and characteristics[J]. J. Geophys. Res., 1997, 1022(D22):26173-26178 [21] POGORELTSEV A I, FEDULINA I N, MITCHELL N J, et al. Global free oscillations of the atmosphere and secondary planetary waves in the mesosphere and lower thermosphere region during August/September time conditions[J]. J. Geophys. Res., 2002, 107(D24):4799 [22] POGORELTSEV A I, VLASOV A A, FRÖHLICH K, et al. Planetary waves in coupling the lower and upper atmosphere[J]. J. Atmos. Sol.-Terr. Phys., 2007, 69(17-18):2083-2101 [23] ALTADILL D, APOSTOLOV E M. Time and scale size of planetary wave signatures in the ionospheric F region:Role of the geomagnetic activity and mesosphere/lower thermosphere winds[J]. J. Geophys. Res., 2003, 108(A11):1403 [24] XIONG J, WAN W, NING B, et al. Planetary wave-type oscillations in the ionosphere and their relationship to mesospheric/lower thermospheric and geomagnetic disturbances at Wuhan (30.6°N, 114.5°E)[J]. J. Atmos. Sol.-Terr. Phys., 2006, 68(3-5):498-508 [25] LIU H L, WANG W, RICHMOND A D, et al. Ionospheric variability due to planetary waves and tides for solar minimum conditions[J]. J. Geophys. Res., 2010, 115(A6):A00G01 [26] YUAN Wei, XU Jiyao, MA Ruiping, et al. First observation of mesospheric and thermospheric winds by a Fabry-Perot interferometer in China[J]. Chin. Sci. Bull., 2010, 55(35):4046-4051 [27] GRUBBS F E. Procedures for detecting outlying observations in samples[J]. Technometrics, 1969, 11(1):1-21 [28] XU Jiyao, SMITH A K, YUAN W, et al. Global structure and long-term variations of zonal mean temperature observed by TIMED/SABER[J]. J. Geophys. Res., 2007, 112(D24):D24106 [29] ZHANG Yiyao, SHENG Zheng, SHI Hanqing, et al. Properties of the long-term oscillations in the middle atmosphere based on observations from TIMED/SABER instrument and FPI over Kelan[J]. Atmosphere, 2017, 8(1):7 [30] YUAN W, LIU X, XU J, et al. FPI observations of nighttime mesospheric and thermospheric winds in China and their comparisons with HWM07[J]. Ann. Geophys., 2013, 31(8):1365-1378 [31] CAO Jinbin. Space weather research[J]. Bull. Chin. Acad. Sci., 2005, 20(4):277-282(曹晋滨. 空间天气学研究进展[J].中国科学院院刊, 2005, 20(4):277-282) [32] PRESS W H, TEUKOLSKY S A, VETTERLING W T, et al. Numerical Recipes in FORTRAN:The Art of Scientific Computing[M]. 2nd ed. New York:Cambridge University Press, 1992:569-577 [33] XIONG Jiangang, YI Fan, KLOSTERMEYER J, et al. The VHF observation and study of nonlinear interaction near mesopause[J]. Chin. J. Radio Sci., 2000, 15(1):84-89(熊建刚, 易帆, KLOSTERMEYER J, 等. 中层顶波非线性相互作用的甚高频雷达观测研究[J]. 电波科学学报, 2000, 15(1):84-89) [34] LIU Xiao, XU Jiyao, ZHANG Shunrong, et al. Thermospheric planetary wavetype oscillations observed by FPIs over Xinglong and Millstone Hill[J]. J. Geophys. Res., 2014, 119(8):6891-6901 [35] PARDO-IGUZQUIZA E, RODRÍGUEZ-TOVAR F J. Implemented Lomb-Scargleperiodogram:Avaluable tool for improving cyclostratigraphic research on unevenly sampled deep-sea stratigraphic sequences[J]. Geo-Mar. Lett., 2011, 31(5-6):537-545 [36] WU D L, HAYS P B, SKINNER W R. A least squares method for spectral analysis of space-time series[J]. J. Atmos. Sci., 1995, 52(20):3501-3511 [37] CAO Wenxiang, ZHANG Shaodong, YI Fan, et al. Variation of the mesopause observed by SABER/TIMED satellite[J]. Chin. J. Geophys., 2015, 55(8):2489-2497
