基于分形的宽带漏波天线研究

张立芳; 王宏建; 刘洋

doi:10.11728/cjss2019.05.677

基于分形的宽带漏波天线研究

doi: 10.11728/cjss2019.05.677

张立芳^1,2,
王宏建^1,2,
刘洋^1,2

1. 中国科学院国家空间科学中心微波遥感重点实验室北京 100190;
2. 中国科学院大学北京 100049

详细信息

作者简介:
张立芳,zhanglifang199504@163.com

中图分类号: V443.4
计量
- 文章访问数: 871
- HTML全文浏览量: 77
- PDF下载量: 63
- 被引次数: 0
出版历程
- 收稿日期: 2018-11-26
- 修回日期: 2019-03-28
- 刊出日期: 2019-09-15

Design and Analysis of a Wide Band Leaky Wave Antenna Based on Fractal

1. Key Laboratory of Microwave Remote Sensing, National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2. University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 设计了一种新型的具有宽频带特性的微带平面漏波天线.该天线由基片集成波导喇叭、抛物面结构和一组30×10单元的微带贴片阵列组成.分析比较了普通贴片和分形结构贴片天线的带宽和辐射特性，发现具有分形结构单元的天线具有更宽的频带和更好的辐射特性.仿真结果表明，采用Minkowski准分形结构贴片单元的漏波天线在18～22GHz内回波损耗都大于10dB，带内增益可达17dB.实测结果表明，天线在18～22GHz内回波损耗大于10dB，在20GHz增益为14dB，适合于卫星应用.这为将其用作对地观测卫星数传天线提供了新的理论支撑.该新型微带平面漏波天线具有高增益、宽频带、小体积、轻质量和波束扫描等优势，可作为航天器天线的优选.
- 漏波天线 /
- 分形 /
- Minkowski准分形 /
- 宽带
Abstract: A planar wide band Leaky Wave Antenna (LWA) is proposed in this paper. The antenna is composed of two substrate integrated waveguide horns, the paraboloid structure and a microstrip patch array with 30×10 units. In order to obtain wide bandwidth and high gain, a Minkowski quasi-fractal is properly designed in each unit cell of the patch array. A comparison between two different designs of conventional patch and fractal patch has been done.The simulated results indicate that the LWA with fractal patches has the impedance characteristics with a frequency bandwidth of 18~22GHz for input return loss more than 10dB and a max gain of 17dB at 20GHz. The measured results show that the return loss of 18~22GHz is greater than 10dB and the peak gain at 20GHz is 14dB. The antenna has the advantages of small size, easy integration, high gain, wide band and beam scanning. It can be widely used in data transmission antenna of satellite.
- Leaky wave antenna /
- Fractal /
- Minkowski quasi-fractal /
- Wide band

HTML全文

参考文献(11)

[1]	YE Yunchang. New waveguide array combined antenna for remote sensing satellite data transmission[J]. Acta Astronaut. Sin., 2003, 24(6):555-562(叶云裳. 用于遥感卫星数传的新型波导阵列组合天线[J]. 宇航学报, 2003, 24(6):555-562)
[2]	YE Yunchang. Technical progress of remote sensing satellite data transmission antenna in China[C]//Proceedings of 2004 academic symposium of general professional committee of aircraft of Chinese astronautical society (Volume ii). Sanya:China academy of space technology, 2005:973-981(叶云裳. 我国遥感卫星数传天线的技术进展[C]//中国宇航学会飞行器总体专业委员会2004年学术研讨会论文集(下册). 三亚:中国空间技术研究院, 2005:973-981)
[3]	JACKSON D R, CALOZ C, ITOH T. Leaky-wave antennas[J]. Proc. IEEE, 2012, 100(7):2194-2206
[4]	GAN Yuchen. Design and simulation of broadband leakage antenna based on substrate integrated ridge waveguide[J]. Vac. Electron. Technol., 2017, 3:32-36(甘雨辰. 基于基片集成脊波导的宽带漏波天线的设计与仿真[J]. 真空电子技术, 2017, 3:32-36)
[5]	YAN N, MA K, ZHANG H, et al. A novel substrate integrated suspended line wideband leaky-wave antenna[J]. IEEE Ant. Wireless Propag. Lett., 2017, 99:1-1
[6]	LI Daotie. Research on Fractal Antenna Technology and Design[D]. Shanghai:Shanghai Jiao Tong University, 2014(李道铁. 分形天线技术与设计研究[D]. 上海:上海交通大学, 2014)
[7]	MA Z, CHAN C H, NG K B, et al. A collimated surface-wave-excited high-impedance surface leaky-wave antenna[J]. IEEE Ant. Wireless Propag. Lett., 2017, 99:1
[8]	XU Xinsen. Research on New Substrate Integrated Waveguide Leakage Antenna[D]. Nanjing:Nanjing University of Posts and Telecommunications, 2017(徐心森. 新型基片集成波导漏波天线的研究[D]. 南京:南京邮电大学, 2017)
[9]	CAI Yang, ZHANG Yingsong, CAO Wenquan, et al. Leakage antenna fed by planar substrate integrated waveguide horn[J]. Acta Microw. Sin., 2016(S1):174-176(蔡洋, 张颖松, 曹文权, 等. 一种平面基片集成波导喇叭馈电的漏波天线[J]. 微波学报, 2016(S1):174-176)
[10]	FU Bing. A New Horn Antenna Based on Substrate Integrated Waveguide[D]. Nanjing:Nanjing University of Science and Technology, 2006(符兵. 基于衬底集成波导的新型喇叭天线[D]. 南京:南京理工大学, 2006)
[11]	LIU Shihua, WANG Hongjian, HAO Qiyan, et al. Large space-borne Ku band gap array antenna——broadband design and thermal deformation analysis[J]. J. Space Sci., 2013, 33(2):207-212(刘世华, 王宏建, 郝齐焱, 等. 大型星载Ku波段波导缝隙阵列天线——宽频带设计及热变形分析[J]. 空间科学学报, 2013, 33(2):207-212)
