Sea Level Pressure Retrieval in Mid-to-low Latitude Regions Using FY-3C/MWHTS Data
-
摘要: 利用风云三号C星(FY-3C)微波温湿探测仪(MWHTS)的实测亮温数据,开展了中低纬度(40°S-40°N)区域海面气压反演研究.MWHTS 118.75GHz氧气通道的辐射亮温测量值与氧气气柱总量密切相关,可用于反演海面气压.根据辐射传输方程分析了MWHTS 8个氧气通道对海面气压的敏感性.结果表明,与位于氧气吸收带中心的通道相比,位于吸收带翼区的探测通道对海面气压的变化更敏感.基于神经网络方法建立了中低纬度海面气压反演算法,通过将反演结果与ERA-Interim再分析数据以及原位观测数据进行对比分析,发现建立的反演算法在中低纬度晴空、云天、雨天条件下,对海面气压的估计精度分别为2.0,3.0和3.5hPa.最后,开展了生成初期热带气旋的反演试验,结果表明反演的海面气压资料对热带低压的判别有一定帮助.
-
关键词:
- 海面气压 /
- FY-3C/MWHTS /
- 被动微波 /
- 反演算法 /
- 热带气旋
Abstract: Sea level pressure is an important meteorological factor and plays a key role in Numerical Weather Prediction (NWP), tropical cyclone forecasting and solar activity studies. However, until recently, sea level pressure data have mainly been provided by in-situ measurements. It is of great significance to obtain sea level pressure with a high spatial and temporal resolution by means of remote sensing. In this study, we investigated the retrieval of sea level pressure over mid-to-low latitude (40°S-40°N) regions using the observations from the Microwave Humidity and Temperature Sounder (MWHTS) onboard the Fengyun-3C (FY-3C) satellite. Sea level pressure sounding is achieved by MWHTS 118.75GHz channels due to their ability to measure the total columnar oxygen absorption. The sensitivity of the MWHTS 118.75GHz channels to surface pressure was analyzed using the radiative transfer equation. Compared with the channels far into the oxygen absorption band, the channels lie on the wing of the band are more sensitive to the change of surface pressure. A statistical retrieval algorithm based on the Back-Propagation (BP) neural networks was established. In-situ buoy measurements and reanalysis data were used to assess the retrieval performance. Results showed that the proposed retrieval algorithm can estimate sea level pressure over mid-to-low latitude areas (40°S-40°N) with the accuracy of 2.0, 3.0, and 3.5hPa for clear-sky, cloudy and rainy conditions, respectively. In addition, several tropical cyclone retrieval experiments showed that the proposed method was useful in the early identification of tropical depression.-
Key words:
- Sea level pressure /
- FY-3C/MWHTS /
- Passive microwave /
- Retrieval algorithm /
- Tropical cyclone
-
[1] FLOWER D, PECKHAM G. A Microwave Pressure Sounder[M]. Pasadena CA:Jet Propulsion Laboratory, 1978 [2] MA Leiming. A new approach to typhoon vortex initialization based on the dynamic retrieval of sea level pressure[J]. Acta Meteor. Sin., 2011, 69(6):978-989(马雷鸣. 基于海平面气压动力反演的台风涡旋初始化方法[J]. 气象学报, 2011, 69(6):978-989) [3] TU Xiaoping, XU Yinglong. Verification of TC track forecasting based on ECMWF mean sea level pressure field[J]. Meteor. Mon., 2010, 36:107-111(涂小萍, 许映龙. 基于ECMWF海平面气压场的热带气旋路径预报效果检验[J]. 气象, 2010, 36:107-111) [4] MIN Q, GONG W, LIN B, et al. Application of surface pressure measurements from O2-band differential absorption radar system in three-dimensional data assimilation on hurricane:Part I. An observing system simulation experiments study[J]. J. Quant. Spectrosc. Radiat. Transfer., 2015, 150:148-165 [5] JIANG Qiongfei, GUO Shengli, LIANG Haowen, et al. Research of EASM decadal variation characteristics based on the EMD method and the relationship with solar activity[J]. Chin. J. Space Sci., 2015, 35(1):50-55(姜琼妃, 郭胜利, 梁浩文, 等. 基于EMD的东亚夏季风年代际变化特征及与太阳活动的关系[J]. 空间科学学报, 2015, 35(1):50-55) [6] TIAN Rongxiang. Solar effect on the relationship between tropical cyclone activity over the west of North Pacific and the stratospheric quasi-biennial oscillation[J]. J. Zhejiang Univ.:Sci. Edi., 2005, 32(3):350(田荣湘. 太阳活动、准两年振荡对西北太平洋热带气旋的影响[J]. 浙江大学学报:理学版, 2005, 32(3):350) [7] LI H, WANG C, HE S, et al. Plausible modulation of solar wind energy flux input on global tropical cyclone activity[J]. J. Atmos. Sol.:Terr. Phys., 2019, 192.DOI:10. 1016/j.jastp.2018.01.018 [8] SHA Wenyu, CAI Jianping. Changes of Pacific and Indian ocean's SST, sea level pressure and their influence on cold summer in east China[J]. Acta Meteor. Sin., 1994, 52(1):117-120(沙文钰, 蔡剑平. 太平洋和印度洋表层水温、海平面气压变化关系及对东亚冷夏的影响[J]. 气象学报, 1994, 52(1):117-120) [9] ZHAO Qiaolian, LI Chongyin. Dipole mode of the sea level pressure anomalies in Asia-Pacific region and the relation to winter climate anomaly in China[J]. Clim. Environ. Res., 2012, 17(1):1-12(赵巧莲, 李崇银. 亚洲-太平洋地区冬季海平面气压异常偶极模与我国冬季气候异常的关系[J]. 气候与环境研究, 2012, 17(1):1-12) [10] HILBURN K A, BOURASSA M A, O'BRIEN J J. Development of scatterometer-derived surface pressures for the Southern Ocean[J]. J. Geophys. Res. Oceans., 2003, 108:3244 [11] HSU C S, WURTELE M G, CUNNINGHAM G F, et al. Construction of marine surface pressure fields from scatterometer winds alone[J]. J. Appl. Meteor., 1997, 36:1249-1261 [12] PATOUX J, BROWN R A. A gradient wind correction for surface pressure fields retrieved from scatterometer winds[J]. J. Appl. Meteor., 2002, 41:133-143 [13] PATOUX J, FOSTER R C, BROWN R A. An evaluation of scatterometer-derived oceanic surface pressure fields[J]. J. Appl. Meteorol. Climatol., 2008, 47:835-852 [14] ZHANG L, HUANG S, DU H. A new method of retrieving typhoon's sea level pressure fields and central positions from scatterometer-derived sea surface winds[J]. Acta. Phys. Sin., 2011, 609(11):119202 [15] ELACHI C, VAN Zyl. Introduction to the Physics and Techniques of Remote Sensing (2ed.)[M]. Hoboken:John Wiley & Sons, 2006 [16] MITCHELL R, O'BRIEN D. Error estimates for passive satellite measurement of surface pressure using absorption in the A band of oxygen[J]. J. Atmos. Sci., 1987, 44:1981-1990 [17] LIN B, HU Y. Numerical simulations of radar surface air pressure measurements at O2 bands[J]. IEEE Geosci. Remote Sens. Lett., 2005, 2(3):324-328 [18] HEALY S B. Surface pressure information retrieved from GPS radio occultation measurements[J]. Quart. J. Roy. Meteor. Soc., 2013, 139:2108-2118 [19] HE J Y, ZHANG S W. Research on global profiles and precipitation retrievals for FY-3C MWHTS[C]//2015 IEEE International Geoscience and Remote Sensing Symposium (IGARSS). Milan:IEEE, 2015:4890-4893 [20] ZHANG S, LI J, WANG Z, et al. Design of the second generation microwave humidity sounder (MWHS-II) for Chinese meteorological satellite FY-3[C]//2012 IEEE International Geoscience and Remote Sensing Symposium. Munich:IEEE, 2012:4672-4675 [21] GUO Y, LU N M, QI C L, et al. Calibration and validation of microwave humidity and temperature sounder onboard FY-3C satellite[J]. Chin. J. Geophys., 2015, 58:20-31 [22] HE Q R, WANG Z Z, HE J Y. Bias correction for retrieval of atmospheric parameters from the microwave humidity and temperature sounder onboard the Fengyun-3C satellite[J]. Atmosphere, 2016, 7:156 [23] DEE D P, UPPALA S M, SIMMONS A J, et al. The ERA-Interim reanalysis:configuration and performance of the data assimilation system[J]. Quart. J. Roy. Meteor. Soc., 2011, 137:553-597 [24] OFFICE M. Handbook of Meteorological Instruments (2ed.)[M]. London:HMSO, 1980 [25] ULABY F T, LONG D G. Microwave Radar and Radiometric Remote Sensing[D]. Ann Arbor:The University of Michigan Press, 2014 [26] LIEBE H, HUFFORD G. Propagation modeling of moist air and suspended water/ice particles at frequencies below 1000 GHz[C]//Electromagnetic Wave Propagation Panel Symposium. Palma de Mallorca:Spain, 1993:1-11 [27] ZHANG Z X. Remote sounding of atmospheric pressure profile from space, part 1:principle[J]. J. Appl. Remote Sens., 2010, 4:2840-2849 [28] HUANG Jin, ZHANG Zhengqiang, ZHANG Yuzhe, et al. High-precision orbit prediction for high-altitude orbit satellite based on ANN model[J]. Chin. J. Space Sci., 2016, 36(1):83-91(黄金, 张正强, 张宇喆, 等. 基于神经网络模型的地球同步卫星高精度轨道预报[J]. 空间科学学报, 2016, 36(1):83-91) [29] TIAN Jianhua. Applications of BP neural networks in forecasting sunspot numbers for solar cycle 23[J]. Chin. J. Space Sci., 1997, 17(3):255-260(田剑华. 用BP神经网络预报模型预报太阳活动第23周的黑子数[J]. 空间科学学报, 1997, 17(3):255-260) [30] U.S. GEOLOGICAL SURVEY. Global land cover characteristics database vs. 1:[DB]. Greenbelt, MD:EROS Data Center Distributed Active Archive Center, 1997. http://edcdaac.usgs.gov/glcc/glcc.html [31] ANDERS U, KORN O. Model selection in neural networks[J]. Neural Networks, 1999, 12:309-323 [32] MARZBAN C. Neural Networks for postprocessing model output:ARPS[J]. Mon. Weather Rev., 2003, 131:1103-1111
