第23和24太阳活动周高纬地磁感应电流分布特性

魏佳筠 左平兵 宋小健 周梓露

魏佳筠, 左平兵, 宋小健, 周梓露. 第23和24太阳活动周高纬地磁感应电流分布特性[J]. 空间科学学报, 2021, 41(4): 537-545. doi: 10.11728/cjss2021.04.537
引用本文: 魏佳筠, 左平兵, 宋小健, 周梓露. 第23和24太阳活动周高纬地磁感应电流分布特性[J]. 空间科学学报, 2021, 41(4): 537-545. doi: 10.11728/cjss2021.04.537
WEI Jiayun, ZUO Pingbing, SONG Xiaojian, ZHOU Zilu. Distribution Characteristics of the Geomagnetic Induced Currents at High Latitude during Solar Cycle 23 and 24[J]. Chinese Journal of Space Science, 2021, 41(4): 537-545. doi: 10.11728/cjss2021.04.537
Citation: WEI Jiayun, ZUO Pingbing, SONG Xiaojian, ZHOU Zilu. Distribution Characteristics of the Geomagnetic Induced Currents at High Latitude during Solar Cycle 23 and 24[J]. Chinese Journal of Space Science, 2021, 41(4): 537-545. doi: 10.11728/cjss2021.04.537

第23和24太阳活动周高纬地磁感应电流分布特性

doi: 10.11728/cjss2021.04.537
基金项目:

国家自然科学基金项目(41731067,42074205)和广东省自然科学基金项目(2019A1515011067)共同资助

详细信息
    作者简介:

    魏佳筠,E-mail:20B958028@stu.hit.edu.cn

  • 中图分类号: P353

Distribution Characteristics of the Geomagnetic Induced Currents at High Latitude during Solar Cycle 23 and 24

  • 摘要: 基于高纬度芬兰Mäntsälä地区近两个太阳活动周期(1999—2017年)天然气传输管道的地磁感应电流(GIC,IGIC)观测数据,统计研究了GIC扰动的分布特征以及强GIC扰动与磁暴和地磁亚暴的相关性.研究发现:95.83%时间段的GIC强度分布在0~1A之间.定义:若某个时间段|IGIC|max> 1A,则认为发生GIC扰动;|IGIC|max>10A,则认为发生强GIC扰动事件.GIC扰动在磁地方时夜侧附近发生的概率最高,这主要与地磁亚暴发生期间电离层电流最剧烈的变化发生在磁地方时夜侧附近有关;强GIC扰动经常爆发式出现,且都发生在磁暴期间,但大多数磁暴并不伴随强GIC扰动事件发生.磁暴急始驱动的强GIC扰动事件较少,由磁层压缩引起地磁场突然增强驱动的强GIC扰动事件持续时间较短;强GIC扰动事件主要发生在磁暴主相和恢复相,由环电流变化驱动的强GIC扰动事件一般持续时间较长且强度较大.



  • [1] WANG Shui, WEI Fengsi. Research progress of space weather in China[J]. Prog. Geophys., 2007, 22(4):1025
    [2] KAPPERNMAN J G, ALBERTSON V D. Bracing for the geomagnetic storms[J]. IEEE Spectrum, 1990, 27(3):27
    [3] WRUBEL J N. Monitoring program protects transformers from geomagnetic effects[J]. IEEE Comput. Appl. Power, 1992, 5(1):10-14
    [4] NGWIRA C M, MCKINNELL L A, CILLIERS P J. Geomagnetic activity indicators for geomagnetically induced current studies in South Africa[J]. Adv. Space Res., 2011, 48(3):529-534
    [5] TRIVEDI N B, VITORELLO Í, KABATA W, et al. Geomagnetically induced currents in an electric power transmission system at low latitudes in Brazil:a case study[J]. Space Weather, 2007, 5(4):1-10
    [6] WATARI S, KUNITAKE M, KITAMURA K, et al. Measurements of geomagnetically induced current in a power grid in Hokkaido, Japan[J]. Space Weather, 2009, 7(3):1-11
    [7] LIU C M, LIU L G, PIRJOLA R. Calculation of GIC in mid-low-latitude power grids based on the plane wave method:a preliminary case study[J]. Space Weather, 2009, 7(S04005):1-9
    [8] BARLOW W H. On the spontaneous electrical currents observed in the wires of the electric telegraph[J]. Philos. Trans. Royal Soc. London, 1849, 139:61-72
    [9] DAVIDSON W F. The magnetic storm of March 24, 1940-ffects in the power system[J]. Edison Elect. Inst. Bull., 1940, 8:365-366
    [10] BOTELER D H, JANSEN VAN BEEK G. August 4, 1972 revisited:a new look at the geomagnetic disturbance that caused the L4 cable system outage[J]. Geophys. Res. Lett., 1999, 26(5):577-580
    [11] PULKKINEN A, VILJANEN A, PAJUNPÄÄ K, et al. Recordings and occurrence of geomagnetically induced currents in the Finnish natural gas pipeline network[J]. J. Appl. Geophys., 2001, 48(4):219-231
    [12] EROSHENKO E A, BELOV A V, BOTELER D, et al. Effects of strong geomagnetic storms on Northern railways in Russia[J]. Adv. Space Res., 2010, 46(9):1102-1110
    [13] PEABODY A W. Consideration of telluric currents effects on pipelines[C]//Solar System Plasma Physics. Amsterdam:North-Holland Publishing Company Academia, 1978
    [14] LANZEROTTI L J. Geomagnetic influences on man-made systems[J]. J. Atmos. Terr. Phys., 1979, 41(7):787-796
    [15] LIU L, GE X, ZONG W, et al. Analysis of the monitoring data of geomagnetic storm interference in the electrification system of a high-speed railway[J]. Space Weather, 2016, 14(10):754-763
    [16] WIK M, PIRJOLA R, LUNDSTEDT H, et al. Space weather events in July 1982 and October 2003 and the effects of geomagnetically induced currents on Swedish technical systems[J]. Ann. Geophys., 2009, 27(4):1775-1787
    [17] HUTTUNEN K E J, KILPUA S P, PULKKINEN A, et al. Solar wind drivers of large geomagnetically induced currents during the Solar Cycle 23[J]. Space Weather, 2008, 6(10):1-8
    [18] KATAOKA R, PULKKINEN A. Geomagnetically induced currents during intense storms driven by coronal mass ejections and corotating interacting regions[J]. J. Geophys. Res. Space Phys., 2008, 113(A3). DOI:10. 1029/2007JA012487
    [19] ZUO P B, WEI F S, FENG X S, et al. The relationship between the magnetic cloud boundary layer and the substorm expansion phase[J]. Sol. Phys., 2007, 242(1/2):167-185
    [20] KAPPENMAN J G. Storm sudden commencement events and the associated geomagnetically induced current risks to ground-based systems at low-latitude and midlatitude locations[J]. Space Weather, 2003, 1(3).DOI:10. 1029/2003SW000009
    [21] ZHANG J J, WANG C, SUN T R, et al. GIC due to storm sudden commencement in low-latitude high-voltage power network in China:Observation and simulation[J]. Space Weather, 2015, 13(10):643-655
    [22] WANG Kairang, LIU Lianguang, LI Yan. A preliminary analysis of the interplanetary causes of geomagnetic induced currents and their grid effects[J]. Astron. J., 2014, 55(5):381-390
    [23] BOTELER D H, WATANABE T, SHIER R M, et al. Characteristics of geomagnetically induced currents in the BC Hydro 500kV system[J]. IEEE Trans. Power Apparatus Syst., 1982, 6:1447-1456
    [24] VILJANEN A, KOISTINEN A, PAJUNPÄÄ K, et al. Recordings of geomagnetically induced currents in the finnish natural gas pipeline-summary of an 11-year period[J]. Geophysica, 2010, 46(1-2):59-67
    [25] PULKKINEN A, THOMSON A, CLARKE E, et al. April 2000 geomagnetic storm:ionospheric drivers of large geomagnetically induced currents[J]. Ann. Geophys., 2003, 21(3):709-717
    [26] VILJANEN A, NEVANLINNA H, PAJUNPÄÄ K, et al. Time derivative of the horizontal geomagnetic field as an activity indicator[J]. Ann. Geophys., 2001, 19(9):1107-1118
    [27] VILJANEN A, PULKKINEN A, PIRJOLA R, et al. Recordings of geomagnetically induced currents and a nowcasting service of the Finnish natural gas pipeline system[J]. Space Weather, 2006, 4(10).DOI: 10.1029/2006SW000234
