Research on Calibration Techniques for Asymmetric Spatial Heterodyne Interferometers
-
摘要: 中高层大气风场探测对于大气模型构建、卫星轨道预测、通信导航保障和空间天气灾害预测具有重要的科学和应用价值。光学干涉仪获取气辉辐射的多普勒频移是大气风场遥感最重要的方法之一。标定光学干涉仪的测风性能对于确保探测精确度有重要意义。本文通过研究非对称空间外差干涉仪的测风原理,提出测风敏感系数的概念,为仪器标定提供理论依据。文中设计并实施了两种典型的标定系统,用以对非对称空间外差干涉仪进行测风标定实验。结合标定过程与结果对这两种标定系统的不确定度以及适用性进行综合评估。声光移频标定系统具有低于±1 m/s的不确定度,并且结构紧凑、易于集成,可作为传递标准,用于地面测风网络的内部校准,反射转盘式标定系统具有广泛的光源适用性。该结果可为测风光学干涉仪的实验室和常规现场标定提供参考。
-
关键词:
- 非对称空间外差干涉仪 /
- 中高层大气风场 /
- 被动光学探测 /
- 标定技术
Abstract: The detection of wind in the middle and upper atmosphere has important scientific and practical value for the construction of atmospheric models, satellite orbit prediction, communication and navigation support, and space weather disaster prediction. The Doppler shift of airglow radiation obtained by optical interferometer is one of the most important methods for remote sensing of atmosphere wind. Ensuring the accuracy of these measurements necessitates the calibration of the wind measurement performance of optical interferometers. In this paper, we propose the concept of wind measurement sensitivity coefficient through studying the wind measurement principle of asymmetric spatial heterodyne interferometer, providing a solid theoretical foundation for instrument calibration. Two typical calibration systems are designed and implemented to calibrate an asymmetric spatial heterodyne interferometer. By examining both the calibration process and results, we conduct a comprehensive evaluation of the uncertainty and applicability of these two systems. The acousto-optic frequency shift calibration system boasts an uncertainty of less than ±1 m/s, coupled with its compact design and ease of integration, making it an ideal transfer standard for internal calibration within ground wind measurement networks. On the other hand, the reflective wheel calibration system demonstrates wide applicability across various light sources. The findings presented in this paper can serve as a valuable reference for both laboratory and routine field calibration of wind-measuring optical interferometers. -
-
