OPTIMIZATION OF ORBIT DESIGN FOR LUNAR SATELLITE
-
摘要: 利用带谐项J2和J3对月球卫星轨道进行了优化设计.首先分析了月球卫星轨道摄动因素对轨道的影响,其次推导了对应于J2和J3项的冻结轨道计算公式,并通过对仅包含月球引力场模型的运动微分方程,直接积分计算轨道的变化进行了验证.最后,通过合理选择初始轨道的偏心率eo和近月点幅角ωo,对月球卫星极轨道进行了优化设计,给出了设计公式并进行了仿真.结果表明,这种优化设计方法是很有效的.Abstract: Orbit design of lunar satellite is optimized by using zonal harmonics J2 and J3. First, the effects of perturbation factors are analyzed. The result shows that the primary perturbation on a low-altitude lunar satellite orbit is the moon’s nonspher-ical gravity field. Second, the formula of frozen orbit are derived in response to J2 and J3 and verified by direct integration of differential equation including only lunar gravity model. In this analysis, all other perturbations (third body perturbation, solar radiation pressure, etc.) are neglected. Finally, polar orbit design is optimized by proper selection of eo and ωo, and simulated. As a numerical result, initial val-ues of 213.49° for argument of perigee and approximately 0.0109 for eccentricity (80×120 km orbit) can limit excursions beyond the ±20 km range within about 70 d on the orbit of α=1838 km. It shows that the optimization method is very useful.
-
Key words:
- Lunar satellite /
- Perturbation /
- Frozen orbit /
- Orbit design /
- Optimization
-
-
