Choice of CCD optical remote sensor parameter
-
摘要: 介绍了由衍射受限非相干成像系统的衍射分辨率引出的截止频率及混叠的概念. 为了对采样成像系统获得的图像质量进行量化, 使用图像质量因子(λF/P)表示探测器对光学系统线扩散函数采样的程度. 进一步分析了光学遥感器参数选择与信噪比的关系. 选择实际的焦距9 m, F 数为18 的空间光学系统, 利用ZEMAX 软件的像模拟功能, 对选择8.75 μm 和13 μm 像元尺寸的CCD 所获得的图像进行了模拟仿真. 仿真获得的结果验证了图像质量因子和信噪比对图像分辨率的影响.Abstract: Image quality is the ultimate target for evaluating an optical remote sensing system. This paper introduces the concept and physical intension of resolution, and educes the concept of optical cutoff frequency and image smearing from the diffraction resolution of diffraction-limited incoherent imaging. To evaluate the image quality of sampling imaging system, the IQF (Image Quality Factor) λF/P is used to perform the sampling extension of CCD. This paper discusses the relation between optical remote sensor and SNR (signal to noise ratio) of the image. Taking advantage of image simulation function of ZEMAX software, the image of a space-based remote sensor with 9 m focal length and F number being 18 optical system is analyzed. The pixel size of the CCD is chosen to be 8.75μm and 13μm . The simulation result validates the influence of λF/P and SNR on image resolution. This result will instruct the choice of CCD optical remote sensor parameter.
-
Key words:
- Optical remote sensor /
- Resolution /
- Image quality /
- Sampling /
- Optical parameter
