Research of Blue/Red Reflecting for Space Silicon Solar Cell
-
摘要: 为改善硅太阳电池在轨工作期间的性能, 通过对空间用太阳电池带通滤波器结构设计和制备工艺的研究, 研制出一种空间用硅太阳电池的带通滤波器并对其性能进行了测试, 结果表明, 采用该带通滤波器可使硅太阳电池在轨工作温度降低6℃~12℃, 输出功率增加1.8%~4.1%. 带通滤波器的研制对于促进高效硅太阳电池的空间应用具有积极意义.Abstract: The non-reflective silicon cells could increase cell efficiency in comparison to cells with smooth surface, while they would also increase the operational temperature as IR and UV energy is efficiently absorbed. This temperature increase completely offsets the initial efficiency gain when the non-reflective silicon cells were used in space. A Blue/Red Reflecting (BRR) for space silicon solar cell has been developed to improve the performance of silicon solar cell. The BRR consists of UVR on the front surface of the coverglass and the IRR on the rear surface produced in method of electron-beam gun evaporation with ion-assisted deposition. The operating temperature reduction between 6℃ and 12℃ and the in-orbit efficiency gains between 1.8% and 4.1% for silicon solar cell with BRR have been predicted. The potential benefits of the BRR are greatest for the non-reflective silicon cells.
-
Key words:
- Blue/Red Reflecting (BRR) /
- Film /
- Silicon solar cell
