Numerical study of EUV wave on 13 February 2009
-
摘要: 结合STEREO卫星的观测和三维磁流体力学数值模拟方法, 采用WSO (Wilcox Solar Observatory)磁场数据和势场源表面模型建立日冕初始磁场, 并在日面活动区加上时变的压强扰动, 对2009年2月13日05:35UT爆发的CME-EUV波(Coronal Mass Ejections-Extreme Ultraviolet wave, 日冕物质抛射-远紫外波)事件进行研究. 从COR1/STEREO-A图像判断, 此次CME前沿速度约340km·s-1, 角宽度约60°; 分析EUVI/STEREO-B 195 Å的差分图像, 可以看到, 环形亮环波前从活动区向四周传播, 亮环波前后面是日冕暗化区, 取四个方向的波前位置进行线性拟合可知, 该EUV波速度为247km·s-1, 数值模拟得到的EUV波速度为245km·s-1, 将计算结果采用IDL可视化后可以看到明显的亮环和暗区结构, 数值模拟结果与卫星观测相一致, 表明该EUV波现象是快磁声波.Abstract: EUV wave is observed in the extreme ultraviolet spectrum as large-scale disturbances phenomenon, often accompanied by a coronal mass ejection. Besides, EUV wave is, when displayed in EUVI 195 Å difference image, a bright ring propagating outside with the subsequent spread of the dark zone. The disturbance can often cover the whole solar disk. The current study explores the CME-EUV wave event that occurred at 05:35UT on 13 February 2009, based on the STEREO satellite observations and the three-dimensional Magnetohydrodynamic (MHD) numerical simulation. We know this CME with 340km·s-1 front velocity and 60° angular width from the COR1/STEREO-A observations. Viewing in EUVI/STEREO-B 195Å running difference images, a bright toroidal wave front propagates outside from the active region, with dimming area following the bright wave front. The fitting velocity of EUV wave from the observation data is 247km·s-1. The numerical simulation shows that the (fast-mode) wave, with legible bright front and dimming structure, propagates in a speed of 245km·s-1. The simulation results turn out to be consistent with the satellite observations and confirm that EUV wave is a fast-mode MHD wave.
-
[1] Thompson B J, Plunkett S P, Gurman J B, et al. SOHO/EIT observations of an Earth-directed CME on May 12, 1997[J]. Geophys. Res. Lett., 1998, 25(14):2465 [2] Moses D, Clette F, Delaboudiniere J P, et al. EIT observations of the Extreme Ultraviolet Sun[J]. Solar Phys., 1997, 175:571 [3] Liu Kai. EUV Observation Research of Coronal Dimming Related Coronal Mass Ejections[D]. Hefei: University of Science and Technology of China, 2009. In Chinese (刘凯. 与CME相关的日冕暗化的EUV观测研究[D]. 合肥: 中国科学技术大学, 2009) [4] Ren Dongbai. The Eruption of a Small Filament in the Quiet Sun[D]. Kunming: Yunnan Astronomical Observatory, Chinese Academy of Sciences, 2008. In Chinese (任冬柏. 暗条爆发及其相关耀斑和日 冕dimming的观测研究[D]. 昆明: 中国科学院云南天文台, 2008) [5] Klassen A, Aurass H, Mann G, et al. Catalogue of the 1997 SOHO-EIT coronal transient waves associated type II radio burst spectra[J]. Astron.Astrophys., 2000, 141(Supp.):357 [6] Thompson B J, Reynolds B, Aurass H, Gopalswamy N, Gurman J B, Hudson H S, et al. Observations of the 24 September 1997 coronal flare waves[J]. Solar Phys., 2000, 193(1/2):161-180 [7] Astrid M. Veronig, Manuela Temmer, Bojan Vrsnak, High-cadence observations of a global coronal wave by STEREO EUVI[J]. Astrophys. J., 2008, 681, L113 [8] Long David M, Gallagher Peter T, James McAteer R T, Bloomeld D Shaun. Deceleration and dispersion of large-scale coronal bright fronts[J]. Astron. Astrophys., 2011, arXiv:1104.4334v1 [9] Long D M, Gallagher P T, McAteer R T J, Bloomeld D S. The kinematics of a globally propagating disturbance in the solar corona[J]. Astrophys. J., 2008, 680, L81 [10] Ma S, Wills-Davey M J, Lin J, Chen P F, Attrill G D R, Chen H, Zhao S, Li Q, Golub L. A new view of coronal waves from STEREO[J]. Astrophys. J., 2009, 707:503 [11] Kienreich I W, Temmer M, Veronig A M. STEREO quadrature observations of the three-dimensional structure and driver of a global coronal wave[J]. Astrophys. J., 2009, 703, L118 [12] Attrill Gemma D R, Alexander J Engell, Meredith J Wills-Davey, Paolo Grigis, Paola Testa. HINODE/XRT and STEREO observations of a diffuse coronal "wave" - coronal mass ejection dimming event[J]. Astrophys. J., 2009, 704:1296 [13] Patsourakos S, Vourlidas A, Wang Y M, Stenborg G, Thernisien A. What is the nature of EUV waves? First STEREO 3D observations and comparison with theoretical models[J]. Solar Physics, 2009, 259(1/2):49-71 [14] Thompson B J, Gurman J B, Neupert W M, et al. SOHO/EIT observations of the 1997 April 7 coronal transient: Possible evidence of coronal moreton waves[J]. Astrophys. J., 1999, 517:151-154 [15] Wang Y M. EIT waves and fast-mode propagation in the solar corona[J]. Astrophys. J., 2000, 543:L89-L93 [16] Wu S T, Zheng Huinan, Wang S, et al. Three-dimensional numerical simulation of MHD waves observed by the Extreme Ultraviolet Imaging Telescope[J]. J. Geophys. Res., 2001, 106(A11):25089-25102 [17] Zheng H N, Zhang Y Y, Wang S, Wang C B, Li B. Propagation of fast magneto-acoustic waves in stratified solar atmosphere[J]. Chin. Phys. Lett., 2006, 23(2):399-402 [18] Wang Hongjuan, Shen Chengcai, Lin Jun. Numerical experiments of wave-like phenomena caused by the disruption of an unstable magnetic configuration[J]. Astrophys. J., 2009, 700, 1716 [19] Wills-Davey M J, DeForest C E, Steno J O. Are "EIT waves" fast-mode MHD waves[J]. Astrophys. J., 2007, 664:556-562 [20] Chen P F, Wu S T, Shibata K, et al. Evidence of EIT and Moreton waves in numerical simulations[J]. Astrophys. J., 2002, 572:L99-L102 [21] Chen P F, Fang C, Shibata K. A full view of EIT waves[J]. Astrophys. J., 2005, 622:1202-1210 [22] Chen P F. EIT waves and coronal magnetic field diagnostics[J]. Sci. China: G, 2009, 52(11):1785-1789 [23] Harra L K, Sterling C. Imaging and spectroscopic investigations of a solar coronal wave: Properties of the wave front and associated erupting material[J]. Astrophys. J., 2003, 587:1429 [24] Patsourakos S, Vourlidas A, et al. "Extreme ultraviolet waves" are waves: First quadrature observations of an extreme ultraviolet wave from STEREO[J]. Astrophys. J., 2009, 700:L182-L186 [25] Han S M, Wu S T, Dryer M. A three-dimensional, time-dependent numerical modeling of super-sonic, super-Alfvenic MHD flow[J]. Comp. Fluids, 1988, 16(1):81-103 [26] Altschuler M D, Gordon N J R. Magnetic fields and the structure of the solar corona I: methods of calculating corona fields[J]. Solar Phys., 1969, 9(1):131-149 [27] Kazuyuki Hakamada. A simple method to compute spherical harmonic coefficients for the potential model of the coronal magnetic field[J]. Solar Phys., 1995, 159(1):89-96 [28] Cohen O, Attrill G D R, Manchester IV W B, et al. Numerical simulation of an EUV coronal wave based on the February 13, 2009 CME event observed by STEREO[J]. Astrophys. J., 2009, 705(1):587
