昆明上空电离层D区电子密度季节变化的首次观测分析

李娜; 陈金松; 丁宗华; 赵振维; 吴健

doi:10.11728/cjss2014.06.809

昆明上空电离层D区电子密度季节变化的首次观测分析

doi: 10.11728/cjss2014.06.809 cstr: 32142.14.cjss2014.06.809

李娜^1, ,,
陈金松^1,2,3,
丁宗华^1,4,
赵振维¹,
吴健¹

1.
中国电波传播研究所电波环境特性及模化技术重点实验室青岛 266107
2.
中国科学院空间科学与应用研究中心北京 100190
3.
中国科学院大学北京 100049
4.
空间天气学国家重点实验室北京 100190

基金项目: 国家自然科学基金项目资助(41104102)

详细信息

通讯作者:

李娜,13884631552@163.com

中图分类号: P352
计量
- 文章访问数: 1605
- HTML全文浏览量: 150
- PDF下载量: 1344
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2013-12-20
- 修回日期: 2014-04-29
- 刊出日期: 2014-11-15

First Observation and Analysis of Seasonal Variation of the Ionosphere D Region Electron Density at Kunming

LI Na^{1
, ,},
CHEN Jinsong^1,2,3,
DING Zonghua^1,4,
ZHAO Zhenwei¹,
WU Jian¹

1.
National Key Laboratory of Electron Magnetic Environment, China Research Institute of Radio Wave Propagation, Qingdao 266107
2.
Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190
3.
University of Chinese Academy of Sciences, Beijing 100049
4.
State Key Laboratory for Space Weather, Beijing 100190

摘要

摘要: 通过分析2008年8月至2009年7月昆明站(25.6°N, 103.8°E) 中频(MF)雷达观测数据, 研究了太阳活动低年电离层D区电子密度的季节变化特性,发现D区电子密度主要呈现半年变化特征, 即在春秋季电子密度较大, 而在夏冬季则较小, 这与国际参考电离层(IRI)预测的年变化趋势不一致, 但与昆明站电离层测高仪的最低回波频率f_min的观测结果相符. 同时比较了D区电子密度半年变化与纬向风半年变化的关系, 发现二者之间保持了非常一致的变化趋势并对这种一致性的内在原因进行了分析.
- 电离层D区 /
- 电子密度 /
- 纬向风 /
- 季节变化
Abstract: The observed data by Kunming MF radar (25.6°N, 103.8°E) from August 2008 to July 2009 are employed to investigate the seasonal variation of the ionosphere D region electron density during low solar activity. The obvious characteristics in D region electron density is semiannual variation with the observed values larger in spring and autumn, smaller in su mmer and winter, which is different from the simulated result by International Reference Ionosphere (IRI). The result conforms to that observed by digital ionosonde. Then, comparison with that of zonal wind shows very good correspondence of changing trend between them. Finally the reasons leading to the correspondence are discussed.
- Ionosphere D region /
- Electron density /
- Zonal wind /
- Seasonal variation

HTML全文

参考文献(27)

[1]	Sechrist J C. Comparison of techniques for measurement of D region electron densities[J]. Radio Sci., 1974, 9(1):137-149
[2]	Nicolet M, Aikin A C. The formation of the D region of the ionosphere[J]. J. Geophys. Res., 1960, 65:1469-1483
[3]	Ishisaka K, Okada T, Hawkins J, et al. Investigation of electron density profile in the lower ionosphere by SRP-4 rocket experiment[J]. Earth Planets Space, 2005, 57:879-884
[4]	Fejer J A. Radio wave probing of the lower ionosphere by cross-modulation techniques[J]. J. Atmos. Terr. Phys., 1970, 32:597-607
[5]	Kudeki E, Milla M, Friedrich M, et al. ALTAIR incoherent scatter observations of the equatorial daytime ionosphere[J]. Geophys. Res. Lett., 2005, 33, L08108, doi: 10.1029/2005GL025180
[6]	Han F, Cu mmer S A. Midlatitude nighttime D region ionosphere variability on hourly to monthly time scales[J]. J. Geophys. Res., 2010, 115, A09323, doi: 10.1029/2010JA015437
[7]	Thomson N R. Daytime tropical D region parameters from short path VLF phase and amplitude[J]. J. Geophys. Res., 2010, 115, A09313, doi: 10.1029/2010JA015355
[8]	Gardner F F, Pawsey J L. A study of the ionospheric D region using partial reflections[J]. J. Atmos. Terr. Phys., 1953, 3:321-324
[9]	Vuthaluru R. Mid-latitude D-region MF Radar Electron Density Observation[D]. Adelaide: Adelaide University, 2003
[10]	Hu Xiong, Zeng Zhen, Zhang Dongya, et al. Observations of the mesosphere and lower thermosphere angular spectrum with an MF radar at Wuhan[J]. Chin. J. Space Sci., 2003, 23(4):256-261. In Chinese (胡雄,曾祯,张冬娅, 等. 武汉中层、低热层大气角谱中频雷达观测[J]. 空间科学学报, 2003, 23(4):256-261)
[11]	Zhang Dongya, Hu Xiong, Zhang Xunxie, et al. Observations of the mesospheric and lower thermospheric mean winds at 30°N with MF radars[J]. Chin. J. Space Sci., 2005, 25(4):267-272. In Chinese (张冬娅,胡雄,张训械,等.北纬30°N中间层和低热层大气平均风中频雷达观测[J]. 空间科学学报, 2005, 25(4):267-272)
[12]	Zhang Shaodong, Yi Fan, Hu Xiong. MF radar observations of tides and their interactions over Wuhan (30°N, 114°E)[J]. Chin. J. Space Sci., 2003, 23(6):430-435. In Chinese (张绍东,易帆,胡雄. 武汉上空(30°N, 114°E)潮汐及其相互作用的MF雷达观测[J]. 空间科学学报, 2003, 23(6): 430-435)
[13]	Zhang Xiuchuan, Yi Fan. MF radar observations of mesospheric tides over Wuhan[J]. Chin. J. Space Sci., 2007, 27(1):29-34. In Chinese (张秀川, 易帆. 武汉上空中层顶区域潮汐的MF雷达观测[J]. 空间科学学报, 2007, 27(1):29-34)
[14]	Zhao L, Chen J S, Ding Z H, et al. First observations of tidal oscillations by an MF radar over Kunming (25.6°N, 103.8°E)[J]. J. Atmos. Sol. Terr. Phys., 2012, doi: 10.1016/j.jastp.2011.04.016
[15]	Li N, Chen J S, Zhao L, et al. The study of eclipse effects in D region based on MF radar measurement[J]. Chin. J. Geophys, 2011, 54(4):942-949. In Chinese (李娜,陈金松,赵蕾, 等. 基于MF雷达观测的D区日食效应的研究[J]. 地球物理学报, 2011, 54(4):942-949
[16]	Zhao Lei, Chen Jinsong, Li Na, et al. MF radar in Kunming and its preliminary observation results[J]. Chin. J. Space Sci., 2011, 31(1):27-33. In Chinese (赵蕾,陈金松,李娜,等.昆明MF雷达及初步探测结果[J]. 空间科学学报, 2011, 31(1):27-33)
[17]	Murayama Y, Igarashi K, Rice D D, et al. Medium frequency radars in Japan and Alaska for upper atmosphere observations[J]. IEICE Trans. Co mmun., 2000, E83-B(9):1996-2003
[18]	Fraser G J, Thorps M R. Experimental investigations of ionospheric/strastospheric coupling in southern mid latitudes-1.Spectra and cross-spectra of stratospheric tem-peratures and the ionospheric f_min parameter[J]. J. Atmos. Terr. Phys., 1976, 38:1003-1011
[19]	Friedrich, M. Torkar K M. FIRI: A semiempirical model of the lower ionosphere[J]. J. Geophys. Res., 2001, 106:21409-21418
[20]	Garcia R R, Dunkerton T J, Lieberman R S, et al. Climatology of the semiannual oscillation in the tropical middle atmosphere[J]. J. Geophys. Res., 1997, 102:26019-26032
[21]	Xiong Nianlu, Tang Cunchen, Li Xingjian. Introduction of Ionospheric Physics[M]. Wuhan: Wuhan University Publishing Company, 1997. In Chinese (熊年禄,唐存琛,李行健. 电离层物理概论[M]. 武汉: 武汉大学出版社, 1997)
[22]	Xu J, Liu H L, Yuan W, et al. Mesopause structure from Thermosphere, Ionosphere, Mesosphere, Energetics, and Dynamics (TIMED)/Sounding of the Atmosphere Using Broadband Emission Radiometry (SABER) observations[J]. J. Geophys. Res., 2006, 112, D09102, doi: 10.1029/2006JD007711
[23]	McHugh M, Magill B, Walker K A, et al. Comparison of atmospheric retrievals from ACE and HALOE[J]. Geophys. Res. Lett., 32, L15S10, doi: 10.1029/2005GL022403
[24]	Grygalashvyly M, Becker E, Sonnemann G R . Wave mixing effects on minor chemical constituents in the MLT region: Results from a global CTM driven by high-resolution dynamics[J]. J. Geophys. Res., 2011, 116, D18302, doi: 10.1029/2010JD015518
[25]	Xu J, Smith A K, Brasseur G P. The effects of gravity waves on distributions of chemically active constituents in the mesopause region[J]. J. Geophys. Res., 2000, 105: 26593-26602
[26]	Xu J, Smith A K, Ma R. A numerical study of the effect of gravity wave propagation on minor species distributions in the mesopause region[J]. J. Geophys. Res., 2003, 108(D3), 4119, doi: 10.1029/2001JD001570
[27]	Liu L, Le H, Chen Y, et al. Features of the middle and low latitude ionosphere during solar minimum as revealed from COSMIC radio occultation measurements[J]. J. Geophys. Res., 2011, 116, A09307, doi:10. 1029/2011JA016691
