星载大型平板缝隙天线结构设计及热变形分析

范文杰; 栗晓鹏; 陈博

doi:10.11728/cjss2014.06.894

星载大型平板缝隙天线结构设计及热变形分析

doi: 10.11728/cjss2014.06.894 cstr: 32142.14.cjss2014.06.894

中国科学院空间科学与应用研究中心微波遥感技术重点实验室北京 100190

基金项目: 空间科学预先研究项目资助(XDA0407970002)

详细信息

通讯作者:

范文杰,fanwenjie@mirslab.cn

中图分类号: V414;TP391.72
计量
- 文章访问数: 1368
- HTML全文浏览量: 150
- PDF下载量: 1301
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2013-12-04
- 修回日期: 2014-02-25
- 刊出日期: 2014-11-15

Structure Design and Thermal Deformation Analysis of Large Spaceborne Flat Slotted Antenna

Key laboratory of microwave remote sensing, Center for Space Science and Application, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 以空间应用需求日益广泛的大型平板缝隙天线为研究对象, 介绍了其结构组成. 为减小天线热变形, 对天线外侧4个安装角的连接方式做了改进设计, 并在极高温和极低温两种工况下进行热变形分析, 得到改进前后两个方案的变形结果. 在极高温工况下, 天线阵面Y向热变形均方根值从改进前的0.52 mm减小到0.3 mm; 在极低温工况下, 天线阵面热变形均方根值从改进前的0.35 mm减小到0.1 mm. 结果表明改进后的方案满足设计要求, 从而确保了天线在轨电性能的指标.
- 热变形 /
- 平板缝隙天线 /
- 结构设计
Abstract: Large spaceborne flat slotted antennas recently boom rapidly in the field of space applications. The structural element of large flat slotted antenna is introduced. A new connected scheme of antenna is put forward and unidirectional floating fixing method is applied to outside four flange of antenna. This fixing method could ensure that antenna move along one certain direction freely when temperature rises or drops. Thermal deformation is analyzed in ultimate high temperature and ultimate low temperature. The results are thermal deformation RMS value in Y direction decreases from 0.53 mm to 0.3 mm in ultimate high temperature and decreases from 0.33 mm to 0.1 mm in ultimate low temperature. It shows that the thermal deformation RMS values satisfy the design requirements on board, so electrical performance can be assured.
- Flat seam antenna /
- Heat deformation /
- Structure design

HTML全文

参考文献(4)

[1]	Zhao Huaicheng, Wu Xidong, Wu Weng. Design method of large millimeter-wave waveguide slot array[J]. J. Nanjing Univ. Sci. Technol.: Nat. Sci., 2010, 34(1):113-116. In Chinese (赵怀诚, 吴锡东, 吴文. 大型毫米波波导缝隙天线阵设计方法研究[J]. 南京理工大学学报: 自然科学版, 2010, 34(1):113-116)
[2]	Wang Wenxiu, Wang Jian, Peng Zhongwei. Analysis and design of Ka-band monopulse large waveguide longitudinal slot array antenna[J]. Res. Progr. SSE, 2013(1):57-62. In Chinese (王文秀, 王建, 彭中卫. Ka波段大型单脉冲平板缝隙天线的分析与设计[J]. 固体电子学研究与进展, 2013(1):57-62)
[3]	Li Long, Zhang Yu, Li Jianying, Liang Changhong. Analysis and design of large waveguide longitudinal slot in Chinese arrays[J]. J. Microwaves, 2002(1):11-14. In Chinese (李龙, 张玉, 李建瀛, 梁昌洪. 大型波导纵缝阵列天线的分析与设计[J]. 微波学报, 2002(1):11-14)
[4]	Yang Yulong, Guan Fuling. Thermal-structural analysis of deployable truss antenna[J]. Chin. J. Space Sci.. 2005, 25(3):235-240. In Chinese (杨玉龙, 关富玲. 可展桁架天线温度场与热变形分析[J]. 空间科学学报, 2005, 25(3):235-240)
