Statistical Analysis of Space Weather Effectson Satellites Anomalies
-
摘要: 基于美国国家地球物理数据中心(NGDC) 2384例和中国19颗卫星的263例卫星故障信息, 结合1963-2012年小时平均的多种空间环境数据, 定量分析了三种卫星故障发生期间的空间要素特征, 探讨单粒子锁定(SEU)、表面充电致静电放电(ESD)和内部深层充电所致电子引起的电磁脉冲(ECEMP)与空间天气事件的可能联系, 得出以下主要结论. (1)大部分SEU和ECEMP发生于空间天气平静时, 但在其前后3日内地磁活动达到了磁暴水平, 相对来说比例最大的发生在Dstmin之后第3日 (48~72h). (2) ESD受地磁活动和高能电子通量影响明显. 与磁暴、相对论电子通量增强事件的季节性相对应, 两分点附近ESD和ECEMP的发生率高; 93.6% 的 ESD发生前后72h内地磁活动达到磁暴水平, 故障发生时间均匀分布在 Dstmin前0~48h 和后0~24h; 54.9%的ESD 发生时处于地磁暴期(Dst <-30nT), 以-50~-30nT的小磁暴水平居多; 40.6%的ESD发生于高能电子通量高水平期(≥ 103pfu, 1pfu =1cm-2·s-1·sr-1), 81.9%的ESD发生前后72h 内高能电子通量峰值≥ 103pfu, 发生率最高时段为电子通量峰值前 48~72h. (3)高能电子对中国同步轨道卫星的SEU影响明显, 42.5% 故障发生 时高能电子通量≥ 103pfu, 故障在峰值前48~72h和峰值后48~72h 的发生概率相当, 约为23.0%. (4)同步轨道卫星SEU受太阳质子事件的影响相对较大, 22.5%的中国同步轨道卫星故障发生前后72h内发生了太阳质子事件, 季节性不明显.Abstract: Based on a large database of satellite anomalies containing 2384 anomalies from NGDC (USA) and 263 malfunctions from 19 satellites of China (CHN), and with a large set of hourly space weather condition parameters data over the period of 1963-2012, this paper quantifies statistically space weather conditions which may induce different spacecraft anomalies including Single Event Upset (SEU), Electrostatic Discharge (ESD) induced by surface charging, and Electron Caused Electromagnetic Pulse (ECEMP) resulting from internal, deep dielectric charging. The results are as follows. (1) Most anomalies of SEU, ECEMP occurred on quiet space conditions, whereas geomagnetic storms tended to happen during the 3 days (72h) before or after satellite anomalies started, and the most probable time for anomalies was on the third day (48~72h) after the minimum Dst (Dstmin). (2) Geomagnetic activities and high-energy electrons showed apparent effects on anomalies of ESD. Occurrence probabilities of ESD and ECEMP clearly increased in equinoxes (March, September), and such seasonal characteristic was consistent with that in occurrence probabilities of magnetic storms and Relativistic Electrons Flux Enhancement Events (REFEE). For 93.6% anomalies of ESD, geomagnetic storms tended to happen during 72h before, after ESD started, and the most probable occurring time was 0~48h before Dstmin or 0~24h after Dstmin. 54.9% anomalies occurred on geomagnetic conditions of Dst <-30nT, and intensities of storms seemingly influenced ESD little. 40.6% anomalies occurred at the time when the hourly >2MeV electron flux is above 10^3pfu (1pfu =1cm-2·s-1·sr-1). For 81.9% anomalies of ESD, the hourly maximum of high-energy electron flux, during 72h before or after ESD started, was above 10^3pfu, and the most probable time interval was 48~72h before electron flux maximum, when 33.3% anomalies occurred. (3) High-energy electrons showed apparent effects on SEU of GEO from CHN database, 42.5% of anomalies occurring on conditions of electron flux ≥ 103pfu. For those anomalies, the hourly maximum of > 2MeV electron flux exceeded 103pfu during 72h before or after which started. The anomaly occurrence probabilities at the time of 48~72h before and 48~72h after electron flux maximum, were comparative, being about 23.0%. (4) Solar Proton Event (SPE) showed more influence on SEU of GEO. SPEs seemed no regular seasonal variations based on data during 1975-2013, while occurrence probabilities of SEUs showed little seasonal dependence. For 22.0% SEUs of GEO from CHN database, SPEs occurred during 72h before or after anomalies started, and SEUs might occur at any time of the 72h before or after the maximum of >10MeV proton flux.
-
[1] Shaw R R, Nanevicz J E, Adamo R C. Observations of electrostatic discharges caused by differential satellite charging[M]//Spacecraft Charging by Magnetospheric Plasmas. New York: AIAA, 1976:61-76 [2] McPherson D A, Schober W R. Spacecraft charging at high altitudes: the SCATHA program[M]//Spacecraft Charging by Magnetospheric Plasmas. Cambridge, MA: MIT Press, 1975:15-30 [3] Allen J H, Wilkinson D C. Solar-terrestrial activity affecting systems in space and on Earth[C]//Proceedings of the Workshop Solar-Terrestrial Predictions IV. Ottawa: NOAA, 1992:18-22 [4] Stephen J H. Hazard to electronic in space[J]. NATO ASI Ser.: E, 1993, 245:407 [5] Feynman J, Gabriel S B. On space weather consequences and predictions[J]. J. Geophys. Res., 2000, 105(A5):10543-10564 [6] Welling D T. The long-term effects of space weather on satellite operations[J]. Ann. Geophys., 2010, 28:1361-1367 [7] Webb F D, Allen J H. 2004. Spacecraft and ground anomalies related to the October-November 2003 solar activity[J]. Space Weather, 1994, 2:S03008, doi:10.1029/ 2004SW000075 [8] Gussenhoven M S, Hardy D A, Rich F, et al. High level spacecraft charging in the low-altitude polar auroral environment[J]. J. Geophys. Res., 1985, 90(A11):11009-11024 [9] Fredrickson A R. Upset related to spacecraft charging[J]. IEEE Trans. Nucl. Sci., 1996, 43:426-441 [10] Pease R L. Total dose issue for microelectronic in space systems[J]. IEEE Trans. Nucl. Sci., 1996, 43:442-452 [11] Baker D N, Li X, Blake J B, et al. Strong electron acceleration in the Earth's magnetosphere[J]. Adv. Space Res., 1998, 21:609-613 [12] Fennell J F, Koons H C, Chen M, et al. Internal charging: A preliminary environmental specification for satellites[J]. IEEE Trans. Plas. Sci., 2000, 28:2029-2036 [13] Farthing W H, Brown J P, Bryant W C. Differential Spacecraft Charging on the Geostationary Operational Satellites[R]. NASA Technical Memorandum 83908, 1982, 43 [14] Baker D N. Satellite anomalies due to space storms[M]// Space Storms and Space Weather Hazards. Daglis I A. Springer, 2001, 38:285-311 [15] Allen J H. Some commonly used magnetic activity indices: their derivation, meaning and use[C]//Proceedings of a Workshop on Satellite Drag. Boulder, Colorado: NOAA, 1982:114-134 [16] Allen J H, Frank L, Sauer H, et al. Effects of the March 1989 solar activity[J]. EOS Trans. AGU., 1989, 70(46):1479-1488 [17] Shea M A, Smart D F, Allen J H, et al. Spacecraft problems in association with episode of intense solar activity and related terrestrial phenomena during March 1991[J]. IEEE Trans. Nucl. Sci., 1992, 39(6):1754-1760 [18] Blake J B, Baker D N, Turner N, et al. Correlation of changes in the outer-zone relativistic electron population with upstream solar wind and magnetic field measurements[J]. Geophys. Res. Lett., 1997, 24:927-930 [19] Vampola A L. Analysis of environmentally induced spacecraft anomalies[J]. J. Spacec. Rocket., 1994, 31:154-159 [20] Iucci N, Levitin A E, Belov A V, et al. Space weather conditions and spacecraft anomalies in different orbits[J]. Space Weather, 2005, 3(1):S01001, doi:10.1029/ 2003SW000056 [21] Zhao Xiangang, Wei Caiying, Han Qi, et al. Research on the relationships between FY-2 meteorological satellite anomalies and space weather[J]. Prog. Geophys., 2011, 26(5):1522-1527. In Chinese (赵现纲, 魏彩英, 韩琦, 等. FY-2(02批)气象卫星异常事件与空间天气关系研究[J]. 地球物理学进展, 2011, 26(5):1522-1527) [22] Gubby R, Evans J. Space environment effects and satellite design[J]. J. Atmos. Solar Terr. Phys., 2002, 64:1723-1733 [23] Dorman L I, Iucci N, Belov A V, et al. Space weather and space anomalies[J]. Ann. Geophys., 2005, 23:3009-3018 [24] Bodeau M. Killer electrons from the angry Sun did not stop the pagers[J]. Space Weather, 2007, 5:S03006, doi: 10.1029/2006SW000266 [25] Feynman J, Gabriel S B. On space weather consequences and predictions[J]. J. Geophys. Res., 2000, 105(A5):10543-10564 [26] Koons H C, Mazur J E, Selesnick R S, et al. The Impact of the Space Environment on Space Systems[R]. Aerospace Technical Report TR-99(1670)-1, 1999 [27] Reeves G D, Morley S K, Friedel R H W, et al. On the relationship between relativistic electron flux and solar wind velocity: Paulikas and blake revisited[J]. J. Geophys. Res., 2011, 116:A02213, doi: 10.1029/2010JA015735 [28] Zhang Xiaofang, Liu Jun, Wu Yaoping, et al. Effect of interplanetary and magnetic activity parameters on relativistic electrons at geosynchronous orbit[J]. Chin. J. Geophys., 2013, 56(10):3223-3235. In Chinese (张晓芳, 刘俊, 吴耀平, 等. 行星际扰动和地磁活动对GEO相对 论电子影响[J]. 地球物理学报, 2013, 56(10):3223-3235) [29] Srivastava N, Venkatakrishnan P. Solar and interplanetary sources of major geomagnetic storms during 1996 -2002[J]. J. Geophys. Res., 2004, 109:A10103, doi: 10.1029/2003JA010175 [30] Gonzalez W D, Tsurutani B T, Gonzalez A L. Interplanetary origin of geomagnetic storms[J]. Space Sci. Rev., 1999, 88:529-562 [31] Zhang Xiaofang, Zha Shixiang, Liu Songtao, et al. Effect of interplanetary disturbances on magnetic activities[J]. Seism. Geomag. Obs. Res., 2011, 32(3):52-61. In Chinese (张晓芳, 査石祥, 刘松涛, 等. 行星际扰动对地磁活动的影响[J]. 地震地磁观测与研究, 2011, 32(3):52-61) [32] Kudela K. Cosmic rays and space weather: Direct and indirect relations[C]//Proceedings of the 30th International Cosmic Ray Conference. Mexico City, Universidad Nacional Autonóma de México, 2009:195-208
