Method on Calculation of Lunar Soil Particles Trajectories Considering Collision Effect
-
摘要: 针对登月着陆器下降过程扬起月壤颗粒的运动轨迹及空间分布问题, 提出了考虑月壤颗粒发生完全弹性碰撞和非完全弹性碰撞两种情况的月壤颗粒运动轨迹计算方法. 根据质量守恒和能量守恒定律确定月壤颗粒相互碰撞后的速度, 通过羽流场与月壤颗粒的流固耦合相互迭代计算方法, 获得被扬起的月壤颗粒在羽流场和相互碰撞共同作用下随时间的运动轨迹和空间分布. 基于美国Apollo 11登月过程实测数据, 采用数值模拟对该方法进行验证. 结果表明, 考虑月壤颗粒相互碰撞的影响后, 其运动规律出现较明显的扩散趋势. 进一步考虑月壤颗粒相互碰撞引起能量损失的影响后, 月壤颗粒的扩散趋势有所减弱, 并且扬起的高度随着恢复系数的减小而降低.Abstract: Regarding to the trajectory and mass distribution of lunar soil particles which are lifted by the lunar lander during the descending stage, a method considering the particles' collision effect is proposed. Based on the law of mass and energy conservation, the speed of regolith particles after collision is determined, and through the iterative calculations of fluid-structure interactions, the mass distribution caused both by collision effect and lunar lander effect on the lunar soil particles is presented. Through the measured data from the US Apollo 11 descending and landing on the lunar surface, the method are tested and verified by the numerical simulation. The analysis result shows that after the regolith particles colliding with each other having been considered, their trajectories have a more obvious tendency to spread. Furthermore, after the collision energy loss having been considered, the tendency to spread of regolith particles is weakened. And the smaller the coefficient of restitution is, the lower the raising height of the lunar soil particle will be.
-
Key words:
- Regolith particles /
- Collision /
- Trajectory /
- Energy loss
-
[1] Fu Xiaohui, Zou Yongliao, Zheng Yongchun, et al. Space weathering processes and effects on the Moon[J]. Chin. J. Space Sci., 2011, 31(6):705-715. In Chinese (付晓辉, 邹永廖, 郑永春, 等. 月球表面太空风化作用及其效应[J]. 空间科学学报, 2011, 31(6):705-715) [2] Zheng Yongchun, Wang Shejie, Liu Jiangzhong, et al. A review and prospect for developing of lunar soil simulants[J]. Chin. J. Space Sci., 2005, 25(1):70-75. In Chinese (郑永春, 王世杰, 刘建中, 等. 模拟月壤研制的初步设想[J]. 空间科学 学报, 2005, 25(1):70-75) [3] Li Jianqiao, Zou Meng, Li Yinwu, et al. Study on the influence of lunar wheel configuration for traction ability[J]. Chin. J. Space Sci., 2008, 28(4):335-339. In Chinese (李建桥, 邹猛, 李因武, 等. 驱动轮结构参数对月球车牵引性能影响研究[J]. 空间科学学报, 2008, 28(4):335-339) [4] Zheng Yongchun, Ouyang Ziyuan. Physical and mechanical properties of the lunar regolith[J]. J. Min. Petrol., 2004, 24(4):14-19. In Chinese (郑永春, 欧阳自远. 月壤的物理和机械性质[J]. 矿物岩石, 2004, 24(4):14-19) [5] Li F, Ke B G, Wang W R, et al. Estimation of the ancient lunar crust thickness from the admittance[J]. Chin. J. Geophys., 2009, 52(8):2001-2007. In Chinese (李斐, 柯宝贵, 王文睿, 等. 利用重力地形导纳估计月壳厚度[J]. 地球物理学报, 2009, 52(8):2001-2007) [6] Zheng Yongchun, Wang Shijie, Feng Junming. Simulated lunar regolith[J]. Acta Momeral. Sin., 2007, 12(27):571-578. In Chinese (郑永春, 王世杰, 冯俊明, 等. CAS-1模拟月壤[J]. 矿物学报, 2007, 12(27):571-578) [7] Ouyang Ziyuan. Introduction to Lunar Science[M]. Beijing: China Astronautic Publishing House, 2005:51-155. In Chinese (欧阳自远. 月球科学概论[M]. 北京: 中国宇航出版社, 2005:151-155) [8] Shi Xiaobo, Li Yunze, Huang Yong, et al. Study on the simulation strategy of lunar dust/ regolith environment effects[J]. Chin. J. Space Sci., 2007, 27(1):66-71. In Chinese (石晓波, 李运泽, 黄勇, 等. 月尘/月壤环境效应地面模拟方法研究[J]. 空间科学学报, 2007, 27(1):66-71) [9] Zhao Chunmei, Zhu Chengmin. Numerical simulation of regolith trajectory under the action of the jet engine[C] //The 23rd National Space Exploration Symposium Abstract Book, 2010. In Chinese (赵春梅, 祝成敏. 发动机喷流作用下月壤运动轨迹数值仿真研究[C]. 第二十三届全国空间探测学术交流会论文摘要集, 2010) [10] He X Y, He B J, Cai G B. Simulation of rocket plume and lunar dust using DSMC method[J]. Acta Astron., 2012, 70:100-111 [11] Cai Guobiao, Wang Huiyu, Zhuang Fenggan. Numerical simulation on vacuum plume and numerical analyzing study on vacuum plume contamination[J]. J. Astron., 1998, 19(3):1-9. In Chinese (蔡国飙, 王慧玉, 庄逢甘. 真空羽流的数值模拟及真空羽流污染的 数值模拟分析研究[J], 宇航学报, 1998, 19(3):1-9) [12] Geng Dongliang, Reng Depeng, Ye Qing, et al. A new calculation method of the interaction between plume particles and lunar regolith[J]. J. Astron., 2014, 35(8):884-892. In Chinese (耿动梁, 任德鹏, 叶青, 等. 羽流场与月壤颗粒相互作用 的一种新计算方法[J]. 宇航学报, 2014,35(8):884-892) [13] Bird G A. Molecular gas dynamics and the direct simulation of gas flows[M]. Oxford: Oxford Science Publication, 1994 [14] Braeunig R A. Lunar Module Blast Crater[EB/OL]. 2011-07-01[2013-05-26]. http://www.braeunig.us/apollo/LMcrater.htm [15] Morris A B, Goldstein D B, Varghese P L, et al. Modeling the interaction between a rocket plume, scoured regolith, and a plume deflection fence[C]//Earth and Space 2012: Engineering, Science, Construction, and Operations in Challenging Environments. Pasadena, California: American Society of Civil Engineers, 2012:189-198
