Research Of Viscous Fluid Damping Isolator Used In Space Telescope
-
摘要: 为抑制卫星平台对天基望远镜的扰动, 需进行减振设计. 设计了一种空间望远镜用黏滞液体阻尼隔振器, 具有密封可靠、空间环境适应性好等特点. 根据流固耦合相关理论建立阻尼参数模型, 在此基础上实现了隔振器结构设计, 并对核心元件弹簧片进行参数优化设计, 加工制作出一套原理样机. 对该样机的刚度和阻尼性能进行了仿真分析和实验测试. 结果表明, 该隔振器的刚度特性和阻尼特性理论分析结果均与实验结果吻合较好, 说明模型较为准确, 具有工程设计指导价值.Abstract: In order to suppress infrared telescope astronomy disturbance caused by the satellite payload, it is needed to design vibration reduction device for the telescope. Therefor a viscous fluid damper used in space is designed, which could be sealed reliably and adapted to the space environment well. Firstly, a damping calculation model based on the theory of fluid mechanics is built. Then, the structure of the damper is designed, and parameters of the spring sheet which was a core component belonging to the damper, are optimized. A set of prototype was manufactured, and a finite element model of the vibration isolation system was created to get the system's first two models. Finally, the simulation results are compared with the experimental results. According to the analysis results, it can be seen that the damper's stiffness characteristics and damping characteristics can meet the design requirement. The theory analysis results coincide with the experimental results, which proves that the finite element model is precise and the prototype has guidance value in engineering design.
-
Key words:
- Telescope /
- Vibration reduction /
- Viscous fluid damping /
- Isolator
-
[1] Wright E L, Eisenhardt P R M, Mainzer A, et al. The Wide-field Infrared Survey Explorer (WISE): Mission description and initial on-orbit performance[J]. Ap. J., 2010, 140:1868-1881 [2] Wilson G W, Wo1ke P J. Performance prediction of D-Strut isolation systems[J]. SPIE Proc., 1997, 3045:236-250 [3] Foshage J, Davis T. Hybrid active/passive actuator for spacecraft vibration isolation and suppression[J]. SPIE Proc., 1996, bf 2865:104-122 [4] Cunningham D D, Harrell J. Advanced 1.5Hz passive viscous isolation system[C]//AIAA SDM Conference. Hilton Head, South Carolina: AIAA, 1994 [5] Anderson E H, Sater J M. SPIE smart structures product implementation award: A review of the first ten years[J]. SPIE Proc., 2007, 6527:652702/1-13 [6] Guan Xin, Zheng Gangtie. Integrated design of space telescope vibration isolation and attitude control[J]. J. Astron., 2013, 32(2):214-221. In Chinese (关新, 郑钢铁. 空间相机隔振与姿态控制一体化设 计[J]. 宇航学报, 2013, 32(2):214-221) [7] Yu Zifei, Zhou Xubin, Shen Junfeng, et al. Design of joint vibration reduction system combined solation and absorption for flywheel[J]. Opt. Prec. Eng., 2014, 4:897-903. In Chinese (虞自飞, 周徐斌, 申军烽, 等. 卫星飞轮隔振与吸振联合减 振系统设计[J].光学精密工程, 2014, bf4:897-903) [8] Zhou Yun. Viscous Damping Shock Absorption Structure Design Theory and Application[M]. Wuhan: Wuhan University of Technology Press, 2013. In Chinese (周云. 粘滞阻尼减震结构设计理论及应用[M]. 武汉: 武汉理 工大学出版社, 2013) -
-
