Design of Unfolded Mechanical Properties Testing System for Multidimensional Deployment Mechanism of Antenna
-
摘要: 卫星天线是卫星通信的关键部件. 为保证天线在轨可靠展开, 必须在地面对天 线展开机构的力学性能进行测试. 针对该问题, 提出一种多维构架式天线展开 机构力学性能测试系统, 模拟空间微重力和高低温环境下天线的展开过程并在 展开过程中对其进行加载测试. 根据测试系统方案及工作原理, 设 计了三自由度的重力补偿机械臂和加载装置, 并对展开机构的加载系统进行了 建模和仿真. 分析表明, 该测试系统重力平衡误差小于2% FS (Full Scale), 力矩加载误差小于2%, 满足展开机构测试要求. 该系统的提出使得展开机构测试从理论仿真提 升为全物理仿真, 对于保证卫星在轨可靠通信具有重要意义.Abstract: Satellite antenna is a key component for satellite communications. In order to ensure the reliability of antenna deployment mechanism in orbit, its mechanical properties must be tested on the ground. To achieve this goal, this paper presents a mechanical performance testing system of antenna deployable mechanism which is in multidimensional framework style. The deployment process of antenna under high or low temperature and weightless environment of space can be simulated, and a loading test during the process could be carried on. The scheme and working principle of the testing system has been illustrated, as well as the innovative design of the three degrees of freedom mechanical arm and the loading mechanism. In addition, the mathematical model of the loading system has been built and simulated. Analyses show that the error of gravity balance is less than 2% FS (Full Scale) and error of the loading moment is less than 2%, thus the system can meet the test requirements of deployable mechanism. The testing system has made it a reality that the test of deployable mechanism has stepped from theoretical simulation stage across to the full-physical simulation stage, which is of great significance to ensure the satellite reliable communications in orbit.
-
Key words:
- Aerial deployment mechanism /
- Test system /
- Microgravity /
- Mechanical properties
-
[1] LIU Rongqiang, TIAN Dake, DENG Zongquan. Research present situation and prospect of unfolded antenna structure in space[J]. Mech. Design, 2010, 27(9):1-10 (刘荣强, 田大可, 邓宗全. 空间可展开天线结构的研究现状与展望[J]. 机械设计, 2010, 27(9):1-10) [2] YOU Bindi, ZHAO Zhigang, ZHAO Yang. The disturbance analysis and inhibition of flexible antenna in the face of spaceborne antenna base[J]. Acta Astron., 2010, 31(12):2348-2356 (游斌弟, 赵志刚, 赵阳. 柔性天线面对漂浮基星载天线扰动分析及抑制[J]. 宇航学报, 2010, 31(12):2348-2356) [3] MA Xingrui, YU Dengyun, SUN Jing, HU Chengwei. The research progress of the drive and deployable mechanism of space vehicle[J]. Acta Astron., 2006, 27(6):1123-1131 (马兴瑞, 于登云, 孙京, 胡成威.空间飞行器展开与驱动机构研究进展[J].宇航学报, 2006, 27(6):1123-1131) [4] ZHOU Weilai, LING Minhe, ZHU Peiyun. The development status and trends of deep space probe antenna technology[J]. Space Electr. Technol., 2011(2):17-21 (周卫来, 凌闽河, 朱培芸. 深空探测 天线技术发展现状及趋势[J]. 空间电子技术, 2011(2):17-21) [5] XU Wenfu, LIANG Bin, LI Cheng, LIU Yu, QIANG Wenyi. The research summary of space robot microgravity simulation experiment system[J]. Robot, 2009, 31(1):88-96 (徐文福, 梁斌, 李成, 刘宇, 强文义. 空间机器人微重力模拟实验系统研究综述[J]. 机器人, 2009, 31(1):88-96) [6] XU Zhigang, WANG Hao, WANG Junyi, BIAN Zhenzhen. Space robot suspension gravity compensation research[J]. Mach. Design Manuf., 2014(10):149-152 (徐志刚, 王昊, 王军义, 边真真. 空间机器人悬挂系统重力补偿研究[J]. 机械设计与制造, 2014(10):149-152) [7] WANG Jian, LI Yongdong. Current loop timing method in the application of PWM rectifier[J]. J. Tsinghua Univ., 2009, 49(10):1-3 (王剑, 李永东. 电流环时序方法在PWM整流器中的 应用[J]. 清华大学学报, 2009, 49(10):1-3) [8] Shanghai Institute of Satellite Engineering. A zero gravity hanging unfold test apparatus:CN201010108589.9[P] (上海卫星工程研究 所. 一种零重力悬挂式展开试验装置:CN201010108589.9[P] [9] ZHOU Qihang. Space Manipulator Ground Zero Gravity Simulation System Design and Analysis[D]. Harbin: Harbin Institute of Technology, 2012 (周啟航. 空间机械臂地面零重力模拟系统设计及分 析[D]. 哈尔滨: 哈尔滨工业大学, 2012) [10] CHEN Xiaoping. The Linear System Theory[M]. Beijing: China Machine Press, 2011 (陈晓平. 线性系统理论[M]. 北京: 机械工业 出版社, 2011) [11] HUANG Zhi, GUO Hong, WANG Dayu, XU Jinquan. Brushless DC torque motor double closed loop control strategy simulation analysis[J]. J. Beijing Univ. Aeron. Astron., 2010, 37(1):72-75 (黄智, 郭宏, 王大彧, 徐金全. 无刷直流力矩电动机双闭 环控制策略仿真分析[J]. 北京航空航天大学学报, 2010, 37(1):72-75) [12] WANG Yajun, XU Zhigang, LI Feng, TONG Xiaoyan, ZHANG Zhijuan. The design of mechanical properties testing system of deployment mechanism on flexible solar wings[J]. Manuf. Autom., 2015, 6(12):62-66 (王亚军, 徐志刚, 李峰, 童小艳, 张志娟. 柔性太阳翼展开机 构力学性能测试系统设计[J]. 制造业自动化, 2015, 6(12):62-66)
