具有死区特性的空间机器人基于干扰观测器的<i>L</i><sub>2</sub>反步控制

戴巧莲; 陈力

doi:10.11728/cjss2017.04.499

具有死区特性的空间机器人基于干扰观测器的L₂反步控制

doi: 10.11728/cjss2017.04.499

戴巧莲,
陈力

福州大学机械工程及自动化学院福州 350116

基金项目:

国家自然科学基金项目资助（11372073，11072061）

详细信息

作者简介:
戴巧莲,E-mail:dql99726@163.com

中图分类号: TP241
计量
- 文章访问数: 1022
- HTML全文浏览量: 49
- PDF下载量: 3253
- 被引次数: 0
出版历程
- 收稿日期: 2016-04-24
- 修回日期: 2017-03-06
- 刊出日期: 2017-07-15

L₂ Back-stepping Control Based on Disturbance Observer for Space Robot under Dead-zone Effect

College of Mechanical Engineering, Fuzhou University, Fuzhou 350116

摘要

摘要: 研究了载体位置及姿态均不受控时空间机器人在惯性空间中的轨迹跟踪问题.考虑到系统存在参数不确定及死区特性等情况，提出了一种基于干扰观测器的L₂反步控制方案.结合拉格朗日方程和系统Jacobi关系矩阵建立系统的动力学模型.利用干扰观测器对系统建模误差进行观测补偿，并通过L₂干扰抑制法对观测误差进行消除，同时采用死区模糊补偿器对系统死区特性造成的影响进行补偿.该控制方案不需要预知准确的惯性参数，不用对惯性参数进行线性化处理，并且不要求估计系统不确定项和死区参数的上界，从而简化了系统的控制.数值仿真证明了该控制方案的有效性.
- 空间机器人 /
- 参数不确定 /
- 干扰观测器 /
- 死区补偿 /
- L₂反步控制
Abstract: The trajectory tracking control problem of space robot system with uncontrolled base is discussed. Considering the existence of uncertain parameter and unknown dead-zone in the space robot, an L₂ back-stepping control scheme based on the disturbance observer is proposed. Firstly, the dynamic model of system in inertia space is established by the combination of the second Lagrange method and Jacobi matrix. Then, the disturbance observer is used to observe and compensate the model error, and the observer error is eliminated by the method of L₂ disturbance suppression. Meanwhile, a fuzzy compensator is used to compensate the bad effect caused by dead-zone. The control scheme doesn't need to know the accurate inertia parameters and linearly parameterize the dynamic model. Moreover, it is not necessary to estimate the upper bound of system uncertainties and the dead-zone parameters, which simplifies the system control. A planar space robot with two links is simulated to verify the feasibility of the control scheme.
- Space robot /
- Uncertain parameter /
- Disturbance observer /
- Dead-zone compensation /
- L₂ back-stepping control

HTML全文

参考文献(14)

[1]	KHALOOZADEH H, HOMAEINEJAD M R. Real-time regulated sliding mode controller design of multiple manipulator space free-flying robot[J]. J. Mech. Sci. Technol., 2010, 24(6):1337-1351
[2]	YE Bingneng, CHEN Li. Time delay estimation of flexible space robot robust H∞ control and vibration suppression[J]. Chin. J. Space Sci., 2016, 36(2):237-244(叶柄能, 陈力. 时延估计柔性空间机器人鲁棒H∞控制及振动抑制[J]. 空间科学学报, 2016, 36(2):237-244)
[3]	LI Junfeng, WANG Zhaolin. Study on attitude dynamics of a liquid-filled spacecraft with manipulator[J]. J. Astron., 1999, 20(2):81-86(李俊峰, 王照林. 带空间机械臂的充液航天器姿态动力学研究[J]. 宇航学报, 1999, 20(2):81-86)
[4]	WANG Zongyuan, CHEN Li. Fuzzy neural networks sliding mode control and active vibration suppression for free-floating space flexible manipulator[J]. Chin. J. Space Sci., 2013, 33(5):569-576(王宗源, 陈力. 柔性空间机械臂系统的模糊滑模神经网络控制及柔性振动主动抑制[J]. 空间科学学报, 2013, 33(5):569-576)
[5]	GE Xinsheng, CUI Wei, ZHAO Qiuling. Trajectory tracking control and vibration suppression of rigid flexible manipulators[J]. Eng. Mech., 2005, 22(6):188-191(戈新生, 崔玮, 赵秋玲. 刚柔性耦合机械臂轨迹跟踪与振动抑制[J]. 工程力学, 2005, 22(6):188-191)
[6]	GUO Wenhao, WANG Tianshu. Pre-impact configuration optimization for a space robot capturing target satellite[J]. J. Astron., 2015, 36(4):390-396(郭闻昊, 王天舒. 空间机器人抓捕目标星碰撞前构型优化[J]. 宇航学报, 2015, 36(4):390-396)
[7]	CHENG Jing, CHEN Li. Adaptive fuzzy H-infinity control of uncertain space robot system[J]. Manned Spaceflight, 2015, 21(1):564-567(程靖, 陈力. 不确定空间机器人自适应模糊控制H∞控制[J]. 载人航天, 2015, 21(1):564-567)
[8]	CHEN Li. Robust and adaptive composite control of space robot system with prismatic joints[J]. Eng. Mech., 2004, 21(3):174-179(陈力. 带滑移铰空间机器人惯性空间轨迹跟踪的鲁棒混合自适应控制[J]. 工程力学, 2004, 21(3):174-179)
[9]	ZHANG Fuhai, FU Yili, WANG Shuguo. Adaptive control of free-floating space robot with inertia parameter uncertainties[J]. Acta Aeron. Astron. Sin., 2012, 33(12):2347-2354(张福海, 付宜利, 王树国. 惯性参数不确定的自由漂浮空间机器人自适应控制研究[J]. 航空学报, 2012, 33(12):2347-2354)
[10]	CHEN Zhiyong, CHEN Li. On-line self-learning compensation control for dual-arm space robot with external disturbance via neural networks[J]. China Mech. Eng., 2010, 21(17):2114-2118(陈志勇, 陈力. 具有外部扰动双臂空间机器人的神经网络在线自学习补偿控制[J]. 中国机械工程, 2010, 21(17):2114-2118)
[11]	LIANG Jie, CHEN Li. Fuzzy Adaptive compensation control for space-based robot system with dual-arm based on Gaussian-type function to track trajectory in joint space[J]. China Mech. Eng., 2010, 21(3):330-336(梁捷, 陈力. 双臂空间机器人基于高斯型函数的姿态、关节运动模糊自适应补偿控制[J]. 中国机械工程, 2010, 21(3):330-336)
[12]	LIU Jinkun. Design of Robot Control System and MATLAB Simulation[M]. Beijing:Tsinghua University Press, 2008(刘金琨. 机器人控制系统的设计与MATLAB仿真[M]. 北京:清华大学出版社, 2008)
[13]	LIU Shuang, MA Caiwen, XING Wei, et al. Fuzzy adaptive control of free-floating space robot based on dead-zone compensator[C]//Proceedings of 2010 International Symposium on Computational Intelligence and Design. Hangzhou:IEEE, 2010:47-51
[14]	HUANG Dengfeng. Intelligent Neural Network Control of Rigid-flexible Hybrid Free-floating Space Robots[D]. Fuzhou:Fuzhou University, 2011(黄登峰. 刚柔混合漂浮基空间机器人系统的智能神经网络控制[D]. 福州:福州大学, 2011)
