Kunpeng-1B sounding rocket nutation analysis and simulation after separation (in Chinese)
-
摘要: 2016年4月鲲鹏elax-1B探空火箭在海南儋州台站发射.箭头与箭体分离之后,瞬间进入大章动运动状态,超出预期设计的技术指标范围.基于这种运动现象,分析了鲲鹏elax-1B头体分离后箭头章动可能的产生原因,建立了稀薄大气下准刚体箭头的姿态动力学方程,并通过数字仿真方法模拟了箭头的章动运动.与实际飞行姿态进行对比,得出了导致章动发散的主要原因,为后续探空火箭的设计提供理论参考.Abstract: Kunpeng-1B sounding rocket was launched successfully by the National Space Science Center of Chinese Academy of Sciences at Danzhou, Hainan on April 27, 2016. The attitude of the payload service system fell into nutation mode after being separated from the launching vehicle, which is beyond the designing limits. In this paper the possible factors triggering the nutation movement are analyzed, the attitude dynamics equations of the payload service system are set up, and the nutation movement is reproduced by numerical simulation. By comparing the simulating nutating results with the real flying nutation, the main elements triggering the nutation are obtained. The results can provide reference for the follow-up sounding rocket designing.
-
Key words:
- Sounding rocket /
- Nutation movement /
- Numerical simulation
-
[1] LI Dayao, LI Linfan. Chinese rocket sounding in the 20th Century[J]. Aerospace China, 2001, (4):16-18(李大耀, 李林藩. 20世纪的中国火箭探空[J]. 中国航天, 2001, (4):16-18) [2] JIANG Xiujie, LIU Bo, YU Shiqiang, et al. Development status and trend of sounding rocket[J]. Sci. Technol. Rev., 2009, 27(23):101-110(姜秀杰, 刘波, 于世强, 等. 探空火箭的发展现状及趋势[J]. 科技导报, 2009, 27(23):101-110) [3] BIAN Chunjiang, LIU Cheng, GAO Dong, et al. The payload service system of KUNPENG-1B sounding rocket[C]//29th National Symposium on Space Exploration. Lhasa:Chinese Society of Space Research, 2016(卞春江, 刘成, 高东, 等. "鲲鹏1B"探空火箭箭头平台系统[C]//第29届全国空间探测学术研讨会. 拉萨:中国空间科学学会, 2016) [4] CHEN Shinian. Design of Control System[M]. Beijing:China Astronautic Publishing, 1996(陈世年. 控制系统设计[M]. 北京:中国宇航出版社, 1996) [5] XU Rui, CUI Hutao, CUI Pingyuan, et al. The active nutation control of the small lunar explorer[J]. High Technol. Lett., 2001, 11(3):82-84, 87(徐瑞, 崔祜涛, 崔平远, 等. 小型月球探测器主动章动控制[J]. 高技术通讯, 2001, 11(3):82-84, 87) [6] LIN H S. Spin-Down and Active Nutation Controller (SDANC) for the Galileo Project[R]. AIAA80-1734. NASA, 1980 [7] LIU Ping'an, GAO Ye, WANG Ge. Influential analysis of the parameter variation of spacecraft system on nutation process[J]. J. Solid Rocket Technol., 2012, 35(6):716-721(刘平安, 郜冶, 王革. 飞行器系统参数变化对章动过程的影响分析[J]. 固体火箭技术, 2012, 35(6):716-721) [8] TANG Xiaoping. Simulation and Analysis on Flight Dynamics for the Launch Vehicle's Ascend Stage[D]. Harbin:Harbin Engineering University, 2013(唐小平. 运载火箭上升段飞行动力学仿真及分析[D]. 哈尔滨:哈尔滨工程大学, 2013)
