Effect of Pressure and Power on Material Experimental Furnace in Space and on the Ground
-
摘要: 天宫二号空间综合材料实验装置的炉内压力和加热功率均影响炉内温场.针对空间与地面对比实验,分析了炉内压力和温场相同时炉丝加热功率的变化,以及炉内温场和炉丝加热功率相同时炉内压力的变化.地面实验时,炉内气体被炉丝加热后,由于重力作用产生对流,从而影响炉膛温度.炉内压力为1atm时,空间与地面实验的加热功率比约为97.5%.空间实验时,由于对流效应减弱,炉内压力变化对其最高温度影响减小.空间与地面的对比实验结果表明,地面炉内压力为空间炉内压力(1atm)的50%时,空间与地面实验的加热功率和温场等参数接近一致.这对于空间高温材料实验装置设计具有重要指导和参考意义.Abstract: By analyzing the change of heating wires power in Tiangong-2 Material Experimental Furnace (TMEF) on the ground and in space, the equivalent pressure in the ground experiments is determined. Due to the gravity on the ground, the gas convection in TMEF has an important influence on the highest temperature of TMEF. The power ratio of the same experiments in space and on the ground is about 97.5% when the pressure in TMEF is 1atm. In space, the change of pressure in TMEF has weak effect on the highest temperature of the furnace. When the TMEF's pressure on the ground is 50% of 1atm in space, the obtained values (the powers and temperatures etc.) for the same experiments in space and on the ground are the same. These results are important to design the heating facility used in space.
-
Key words:
- Heating power /
- Experimental furnace /
- Furnace pressure /
- Space experiment /
- Ground experiment
-
[1] GU Yidong, GAO Ming, ZHAO Guangheng. The space sciences and application projects in space laboratory[J]. Chin. J. Space. Sci., 2016, 36(5):626-632 [2] WANG Kang, XING Shurong. Low vacuum as a ground simulation method for studies of gas convection heat transfer inside manned spacecraft[J]. Space Med. Med. Eng., 1998, 11(6):415-419(王康, 邢树荣. 利用低真空环境在地面模拟载人航天器内部气体对流散热的探讨[J]. 航天医学与医学工程, 1998, 11(6):415-419) [3] TAO Ye, YANG Liping, ZHONG Qiu, et al. Simulation and ground experiment investigation of material experimental furnace in space[J]. Chin. J. Space Sci., 2016, 36(4):464-468(陶冶, 杨丽萍, 钟秋, 等. 空间材料实验炉的模拟热分析与地面试验分析[J]. 空间科学学报, 2016, 36(4):464-468) [4] LIU Yunlong, LIANG Xingang, REN Jianxun, et al. Ground thermal scale modeling of radiation-convective heat and mass transfer system in microgravity environment[J]. Chin Space Sci. Technol., 1997, 27(2):8-15 [5] LI Jindong, SHAO Dongbin. Numeric analysis on a microgravity heat convection for a spacecraft pressured cabin[J]. J. Eng. Thermophys., 2002, 23(3):333-335
