星载辐照剂量深度分布探测仪设计

孙莹; 张斌全; 张效信; 张鑫; 张申毅; 沈国红; 常峥; 王春琴; 孙越强; 宗位国; 郭建广; 薛炳森; 张立国; 陈强; 张如意

doi:10.11728/cjss2021.05.793

星载辐照剂量深度分布探测仪设计

doi: 10.11728/cjss2021.05.793 cstr: 32142.14.cjss2021.05.793

孙莹^1,2,3,
张斌全^1,2,3,
张效信⁴,
张鑫^1,2,3,
张申毅^1,2,3,
沈国红^1,2,3,
常峥^1,2,3,
王春琴^1,2,3,
孙越强^1,2,3,
宗位国⁴,
郭建广⁴,
薛炳森⁴,
张立国⁵,
陈强⁵,
张如意¹

1. 中国科学院国家空间科学中心北京 100190;
2. 天基空间环境探测北京市重点实验室北京 100190;
3. 中国科学院空间环境态势感知技术重点实验室北京 100190;
4. 国家卫星气象中心北京 100081;
5. 上海卫星工程研究所上海 201109

详细信息

作者简介:

孙莹,E-mail:sunying@nssc.ac.cn

中图分类号: V45;TN956
计量
- 文章访问数: 796
- HTML全文浏览量: 178
- PDF下载量: 40
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2020-04-23
- 修回日期: 2020-12-24
- 刊出日期: 2021-09-15

Design Spaceborne of Radiation Dosimeter in Depth

1. National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2. Beijing Key Laboratory of Space Environment Exploration, Beijing 100190;
3. Key Laboratory of Science and Technology on Space Environment Situational Awareness, Chinese Academy of Sciences, Beijing 100190;
4. National Satellite Meteorological Center, Beijing 100081;
5. Shanghai Institute of Satellite Engineering, Shanghai 201109

摘要

摘要: 空间带电粒子对在轨航天器会产生辐照剂量效应，严重时可导致星载设备及航天器等的性能衰减及寿命下降，因此采用了星内多点多方位的辐照总剂量探测技术.在中国首次采用深度剂量监测方案.每个探头设置5个剂量监测点，对应屏蔽厚度分别为0（开窗），1mm，2.5mm，3.5mm，6mm的铝结构，探测剂量总量程为2×10⁶rad （Si），最高灵敏度为1rad （Si）.所设计的星载辐照剂量深度分布探测仪可以对卫星在轨遭受的辐照剂量进行实时监测和预警，其探测结果用于研究星内剂量深度分布，对卫星载荷在轨工作状态进行分析评估，并为后续卫星的抗辐照加固设计提供依据.
- 辐照剂量 /
- 剂量深度分布监测 /
- 抗辐照加固 /
- 空间环境
Abstract: In view of the radiation dose effect of space charged particles on spacecraft in orbit, which leads to performance degradation and life decline of onboard equipment and aerospace materials, a multi-point and multi-directional total radiation dose detection technology in satellite is proposed. The scheme of dose monitoring in depth is adopted for the first time in China. Each probe is equipped with five dose monitoring points, corresponding to the aluminum structure with shielding thickness of 0 (open window), 1mm, 2.5mm, 3.5mm and 6mm. The total detection dose range is 2×10⁶rad (Si), and the highest sensitivity is 1rad (Si). The on-board radiation dosimeter in depth will carry out real-time monitoring and early warning of the radiation dose suffered by the satellite in orbit. The detection results will be used to carry out the research on the depth distribution of the dose in the satellite, which is conducive to the analysis and evaluation of the working state of the satellite load in orbit, and provide a reliable basis for the follow-up anti-radiation hardening design of the satellite.
- Irradiation dose /
- Dose monitoring in depth /
- Anti-irradiation hardening /
- Space environment

HTML全文

参考文献(7)

[1]	DYER C S, WATSON C J, PEERLESS C I, et al. Measurements of the radiation environment from CREDO-11 on STRV&APEX[J]. IEEE Trans. Nucl. Sci., 1996, 43(6):2751-2757
[2]	BUHLER P, DESORGHER L, ZEHNDER A, et al. Observations of the low earth orbit radiation environment from MIR[J]. Radiation Meas., 1996, 26(6):917-921
[3]	BOGORAD A, BOWMAN C, DENNISS A, et al. Integrated environmental monitoring system for spacecraft[J]. IEEE Trans. Nucl. Sci., 1995, 42(6):2051-2057
[4]	MACKAY G F, THOMSON I, SULTAN N, et al. Applications of MOSFET dosimeters on MIR and BION satellites[J]. IEEE Trans. Nucl. Sci., 1997, 44(6):2048-2051
[5]	UNDERWOOD C I, BROCK D J, WILLIAMS P S. Radiation environment measurements with the comic ray experiments on-board the KITSAT-1 and POSAT-1 micro-satellites[J]. IEEE Trans. Nucl. Sci., 1994, 41(6):2353-2360
[6]	(杨晓超, 王世金, 王月, 等. 太阳同步轨道空间粒子辐射剂量探测与研究[J]. 宇航学报, 2008, 29(1):357-361 YANG Xiaochao, WANG Shijin, WANG Yue, et al. Observation and research of space particle radiation dose on sun-synchronous orbit[J]. J. Astronaut., 2008, 29(1):357-361
[7]	SUN Jing, GUO Qi, ZHANG Jun, et al. Influence of dose rate on radiation response of PMOSFET dosimeter[J]. Microelectronics, 2009, 39(1):128-131(孙静, 郭旗, 张军, 等. 剂量率对PMOS剂量计辐射影响的研究[J]. 微电子学, 2009, 39(1):128-131)
