Output Feedback Finite-dimensional Repetitive Learning Control on Virtual Force for Flexible-base Flexible-link and Flexible-joint Space Robot
-
摘要: 探讨了基座、关节、臂均存在柔性情况下,空间机器人关节轨迹运动及多重柔性振动的主动控制和主动抑制问题.结合线性弹簧、扭转弹簧、简支梁及假设模态法,利用拉格朗日方程建立了基座、关节、臂全柔性影响下的空间机器人系统动力学模型,利用奇异摄动法,将模型分解为关节运动慢变子系统与关节柔性振动快变子系统.为控制慢变子系统中载体姿态、关节刚性运动并且抑制臂的柔性振动,依据虚拟控制力的概念,设计了基于有限维傅里叶级数解析周期信号的输出反馈重复学习算法.李雅普诺夫直接法证实了上述控制器的稳定性.为了抑制快变子系统中基座和关节的柔性振动,分别采用线性二次最优控制方法以及引入关节柔性补偿器间接增大关节等效刚度的方式,使控制算法不局限于求解弱非线性问题.系统数值仿真结果表明,所提出的控制器能够有效抑制机器人多重柔性构件的振动,实现对期望信号的高品质追踪.Abstract: Motion control and flexible vibration synchronous suppression of base, links and joints for flexible space robot are studied. By combining linear spring, torsion spring, simply supported beam and hypothetical modal method, and using Lagrange equation, the dynamic model of flexible-base, flexible-link and flexible-joint space robot is established. Then, by using singular perturbation method, the model is decomposed into a joint motion slow subsystem and joint flexible vibration fast subsystem. In order to control the rigid motion of the base and joints in the slow subsystem and suppress flexible vibration of links, according to the concept of virtual control force, an output feedback repetitive learning algorithm based on the finite-dimensional Fourier series analytical periodic signal is proposed. The algorithm uses virtual force to suppress the flexible vibration of the robotic links. The output feedback method is designed so that the controller can be implemented based on position measurement only. It is proposed that the repetitive learning algorithm can effectively compensate for repeated errors in periodic tasks and improve the control quality of the system. The Lyapunov direct method confirms the stability of the above controller. In addition, in order to suppress the flexible vibration of the base and joint in the fast subsystem, the linear quadratic optimal control method and the joint flexible compensator are used to indirectly increase the joint equivalent stiffness, so that the control algorithm cannot be limited to solving the weak nonlinear problem. Simulation results show that the proposed controller can effectively suppress the vibration of multiple flexible components of the system, and achieve high-quality tracking of the desired signal.
-
Key words:
- Flexible base /
- Flexible links /
- Flexible joints /
- Space robot /
- Output feedback
-
[1] ZHOU Y Q, LUO J J, WANG M M. Dynamic coupling analysis of multi-arm space robot[J]. Acta Astronaut., 2019, 160:583-593 [2] GE Xinsheng, ZHANG Qizhi, LIU Yanzhu. An optimized method to control the motion planning of space manipulators base genetic algorithm[J]. Chin. J. Space Sci., 2000, 20(2):185-191(戈新生, 张奇志, 刘延柱. 基于遗传算法的空间机械臂运动规划的最优控[J]. 空间科学学报, 2000, 20(2):185) [3] CHENG Lei, WANG Tianshu, LI Junfeng. Attitude dynamics and control of a flexible multi-body satellite[J]. J. Tsinghua Univ.:Sci. Technol., 2005, 45(11):1506-1509(程磊, 王天舒, 李俊峰. 挠性多体卫星姿态动力学与控制[J]. 清华大学学报:自然科学版, 2005, 45(11):1506-1509) [4] KUMAR A, PATHAK P M, SUKAVANAM N. Trajectory control of a two DOF rigid-flexible space robot by a virtual space vehicle[J]. Robot. Auton. Syst., 2013, 61(5):473 [5] STIEBER M E, TRUDEL C P, HUNTER D G. Robotic systems for the international space station[C]//Proceedings of the 1997 IEEE International Conference on Robotics and Automation Albuquerque. New Mexico:IEEE, 1997:3068-3073 [6] EVANS L. Canadian space robotics on board the international space[C]//2005 CCToMM Symposium on Mechanism, Machines, and Mechatronics. Montreal:Canadian Space Agency, 2005:26-27 [7] MASOUDI R, MAHZOON M. Maneuvering and vibrations control of a free-floating space robot with flexible arms[J]. J. Dynam. Syst. Meas. Control, 2011, 133(5):1 [8] ZHENG Tong, ZHANG Dingguo, HONG Jiazhen. Dynamic modeling and simulation for three dimensional flexible beam systems with large deformations[J]. J. Mech. Eng., 2016, 52(19):81-87(郑彤, 章定国, 洪嘉振. 三维大变形梁系统的动力学建模与仿真[J]. 机械工程学报, 2016, 52(19):81-87) [9] YANG B J, CALISE A J, CRAIG J I. Adaptive output feedback control of a flexible base manipulator[J]. J. Guid. Control Dynam., 2007, 30(4):1068-1080 [10] NI Z Y, LIU J G, WU Z G, et al. Identification of the state-space model and payload mass parameter of a flexible space manipulator using a recursive subspace tracking method[J]. Chin. J. Aeronaut., 2019, 32(2):513-530 [11] CHU M, JIA Q X, SUN H X. Backstepping control for flexible joint with friction using wavelet neural networks and L2-gain approach[J]. Asian J. Control, 2017, 20(2):856-866 [12] YU X Y, CHEN L. Observer-based two-time scale robust control of free-flying flexible-joint space manipulators with external disturbances[J]. Robotica, 2017, 35(11):2201 [13] HUANG Xiaoqin, CHEN Li. Finite time control of space robot with elastic base and flexible arms[J]. Chin. J. Space Sci., 2019, 39(3):399-406(黄小琴, 陈力. 基座与臂杆全弹性空间机器人的有限时间控制[J]. 空间科学学报, 2019, 39(3):399-406) [14] FU Xiaodong, CHEN Li. An input limited repetitive learning control of flexible-base two-flexible-link and two-flexible-joint space robot with integration of motion and vibration[J]. Chin. J. Theoret. Appl. Mech., 2020, 52(1):171-183(付晓东, 陈力. 全柔性空间机器人运动振动一体化输入受限重复学习控制[J]. 力学学报, 2020, 52(1):171-183) [15] WANG H H, SU Y X, ZHANG L Y. Global output feedback finite-time regulation of robot manipulators under actuator constraints[J]. J. Dynam. Syst. Meas. Control:Trans. ASME, 2017, 139(6):1-10 [16] FU X D, CHEN L. Repetitive learning control based on terminal sliding mode of space manipulator system with elastic base and two flexible joints[C]//70th International Astronautical Congress (IAC). Washington DC:United States, 2019 [17] CALIFANO F, BIN M, MACCHELLI A, et al. Stability analysis of nonlinear repetitive control schemes[J]. IEEE Control Syst. Lett., 2018, 2(4):773-778 [18] SUN Y G, QIANG H Y, MEI X, et al. Modified repetitive learning control with unidirectional control input for uncertain nonlinear systems[J]. Neural Comput. Appl., 2018, 30(6):2003-2012 [19] SPONG M W. Modeling and control of elastic joint robots[J]. J. Dynam. Syst. Meas. Control, 1987, 109(4):310-319 [20] KELLY R, SANTIBANEZ V, LORIA A. Control of Robot Manipulators in Joint Space[M]. London:Springer Verlag, 2005
