Research on Key Performance Test Methods of Digital Subsystem of Marine Salinity Satellite Integrated Aperture Radiometer
-
摘要: 我国首颗海洋盐度探测卫星L波段一维综合孔径辐射计数字子系统采用分布式结构,由多台独立并行工作的分布式前置数采单机和综合数字单机及同步时钟单机组成,子系统的关键性能包括所有中频模数转换(Analog-to-Digital,AD)通道的相位一致性、幅度一致性和相关偏置等。子系统性能测试分为硬件性能测试和总体性能测试;纯硬件性能测试提出了利用子系统内的同步脉冲控制接口作为触发源,并将其周期加大以适应手动控制,从FPGA调试用ILA接口同步抓取各前置数采单机所有AD采集通道在同一时刻的原始采集序列,通过分析处理得到子系统硬件性能;通过提取科学数据包中的互相关、自相关信息进行分析得到子系统包括软件性能的总体性能;并且设计试验验证测试方法正确。通过对地面原理样机进行测试,所得幅度一致性≤0.4dB、相位一致性≤1度、相关偏置≤-35dB,符合仪器指标要求。Abstract: The digital subsystem of the first spaceborne L-band one-dimensional synthetic aperture radiometer of China adopts a distributed structure, consisting of multiple independent, parallel working distributed front-end data acquisition units, integrated digital units, and synchronization units. The key performance of the subsystem includes phase consistency and amplitude consistency of all intermediate frequency AD acquisition channels of the distributed front-end data acquisition units. The subsystem performance tests aim at independent hardware performance and the whole digital subsystem performance. The testing of distributed front-end data acquisition units for hardware performance utilizes the synchronization pulse within the digital subsystem as a trigger signal to obtain the raw acquisition sequences of all AD channels simultaneously. The performance of the whole digital subsystem is measured by extracting the cross-correlation and auto-correlation information from the scientific data packets for processing. The ground prototype testing obtained the phase consistency of multi-channels under 1°, amplitude consistency under 0.4dB, and correlation offset under -35dB, which reaches to the instrument index requirements and also proves the correctness of the testing method.
-
-
