Time Delay Estimation of Flexible Space Robot Robust H∞ Control and Vibration Suppression
-
摘要: 讨论了参数不确定漂浮基柔性空间机器人关节空间的轨迹跟踪及柔性振动 主动抑制问题. 结合时延估计和鲁棒H∞控制的优点, 设计了时 延估计鲁棒H∞控制器跟踪期望轨迹. 采用时延估计在线获得 系统的未知动力学, 并对控制过程加以补偿. 引入L2增益控制对时延估 计误差的L2干扰进行抑制,进一步提高系统的鲁棒性. 理论分析证明 引入的L2增益控制能够将时延估计误差对系统的影响抑制到满足鲁棒H∞性能, 且闭环系统的所有信号都是有界的. 运用虚拟控制力 改造了原有方案, 致使仅通过一个控制输入便可实现既跟踪期望轨迹又抑制 柔性振动的控制目标. 仿真实验证明了所提控制方案的有效性, 对比结果证 明了柔性振动主动抑制的有效性.
-
关键词:
- 漂浮基柔性空间机器人 /
- 时延估计 /
- 鲁棒H∞控制 /
- 混合轨迹
Abstract: This paper discusses the trajectory tracking and vibration suppression of free-floating flexible space robot with uncertain system parameters, which combines the advantages of time delay estimation control and robust H∞ control. Time-delayed estimation is used to achieve unknown dynamics of space robot system online and to perform a compensation during the tracking control. L2 gain control is employed to achieve L2 interference suppression of time-delay estimation error, which could further improve the robustness of the system. At the same time, theoretical analysis proves that the introduction of L2 gain control can suppress the influence of time delay estimation error on the system to satisfy the robust H∞ performance, and ensures all signals in the closed-loop system to be bounded. In addition, the virtual control force is proposed to transform the original control scheme, which can achieve both tracking the desired trajectory and suppressing the flexible vibration control target through only one control input. Simulation results and comparison chart are given to illustrate the effectiveness of the proposed control scheme and the active vibration suppression of flexible. -
[1] GE Xinsheng, SUN Pengwei. Nonholonomic motion planning of space manipulator system using particle swarm optimization[J]. Chin. J. Mech. Eng., 2007, 43(4):34-38 (戈新生,孙鹏伟.自由漂浮空间机械臂非完整运动规划 的粒子群优化算法[J]. 机械工程学报, 2007, 43(4):34-38) [2] CHEN Li, LIU Yanzhu. Adaptive and robust control of coordinated motion of space-based robot system[J]. Chin. J. Mech. Eng., 2001, 37(8):18-22 (陈力, 刘延柱. 漂浮基空间机器人协调运动的自适应控制与鲁棒控制[J]. 机械工程学报, 2001, 37(8):18-22) [3] WANG Congqing, KE Changjun. Hybrid vibration suppression for a free-floating flexible dual-arm space robot[J]. J. Vibr. Eng., 2009, 22(1):31-35 (王从庆,柯昌俊. 自由浮动柔性空间双臂机器人的混合抑振控制[J]. 振动工程学报, 2009, 22(1):31-35) [4] GE Xinsheng, CUI Wei, ZHAO Qiuling. Trajectory tracking control and vibration suppression of rigid flexible manipulators[J]. Eng. Mech., 2005, 22(6):188-191 (戈新生, 崔玮, 赵秋玲. 刚柔性耦合机械臂轨迹跟踪与振动抑制[J]. 工程力学, 2005, 22(6):188-191) [5] LIU Haitao, ZHANG Tie. Tracking control of industrial robot based on time delay estimation and robust H∞ control[J]. J. South China Univ. Technol., 2012, 40(2):77-87 (刘海涛, 张铁. 基于时延估计和鲁棒H∞控制的工业机器人跟踪控制[J]. 华南理工大学学报, 2012, 40(2):77-87) [6] CHANG Pyunghun, SUK Hopark. On improving time-delay control under certain hard nonlinearities[J]. Mechatronics, 2003, 13(4):393-412 [7] WU Min, HE Yong, YU Jinhua. Robust Control Theory[M]. Beijing: Higher Education Press, 2010 (吴敏, 何勇, 余锦华. 鲁棒控制理论[M]. 北京: 高等教育出版社, 2010) [8] XIE Limin, CHEN Li. Robust control and vibration suppression of free-floating flexible space robot[J]. Chin. J. Theor. Appl. Mech., 2012, 44(6):1057-1065 (谢立敏, 陈力. 漂浮基柔性空间机器人的鲁棒控制及振动抑制[J]. 力学学报, 2012, 44(6):1057-1065) [9] LIANG Jie, CHEN Li. Dual-loop integral sliding mode control for flexible space manipulator[J]. China Mech. Eng., 2011, 22(16):1906-1912 (梁捷, 陈力. 柔性空间 机械 臂系统的双环积分滑膜控制[J]. 中国机械工程, 2011, 22(16): 1906-1912) [10] CAI Guoping, HONG Jiazhen. Assumed mode method of a rotating flexible beam[J]. Acta Mech. Sin., 2005, 37(1):48-56 (蔡国平,洪嘉振. 旋转运动柔性梁的假设模态方法研究[J]. 力学学报, 2005, 37(1):48-56) [11] HAN Dongki, CHANG Pyunghun. Robust tracking of robot manipulator with nonlinear friction using time delay control with gradient estimator[J]. J. Mech. Sci. Technol., 2010, 24(8):1743-1752 [12] PENG Jinzhu, WANG Yaonan, WANG Jie. Robust H-infinity tracking-control for robotic system based on recurrent fuzzy-neural-networks[J]. Control Theor. Appl., 2010, 27(9):1145-1151 (彭金柱, 王耀南, 王杰. 基于递归模糊神经网络的机器人鲁棒H∞跟踪控制[J]. 控制伦理与应用, 2010, 27(9):1145-1151) [13] JIN Maolin, LEE Jinoh, CHANG Pyunghun, et al. Practical nonsingular terminal sliding-mode control of robot manipulators for high-accuracy tracking control[J]. IEEE Trans. Industr. Electron., 2009, 56(9):3593-3601 [14] WANG Zongyuan, CHEN Li. Fuzzy neural networks sliding mode control and active vibration suppression for free-floating space flexible manipulator[J]. Chin. J. Space Sci., 2013, 33(5):569-576 [15] PATEL R V, TODA M, SRIDHAR B. Robustness of linear quadratic state feedback designs in the presence of system uncertainty[J]. IEEE Trans. Autom. Control, 1978, 21:945-949 -
