Atmospheric Temperature and Humidity Profile Retrieval Algorithm Based on Transformer and FY-3E GNOS Validation
-
摘要: 大气温湿廓线是卫星遥感反演、数值天气预报和气候模式模拟的关键输入参数。风云系列卫星搭载的掩星探测仪(GNOS)已实现全球大气参数的连续观测,为天气预报和极端天气监测提供了重要数据支撑,但在近地面边界层受下垫面影响,探测精度有待提升。探空气球观测精度高但时间分辨率有限,每日仅两次,难以支撑连续卫星校验;地基微波辐射计通过接收大气下行辐射亮温实现温湿廓线连续反演,不受下垫面限制,为卫星数据比对校验提供了重要途径,但传统反演方法在边界层精度有限。本文对Transformer进行了面向大气反演任务的改进设计,利用北京南郊观象台2020—2025年探空气球实测数据及MonoRTM辐射传输模型正演构建训练集,建立了基于自注意力机制的地基反演模型,并与线性回归、BP神经网络进行了对比。结果表明:Transformer反演精度较线性回归和BP神经网络显著提升,温度RMSE分别降低29.7%和10.1%,绝对湿度RMSE分别降低26.8%和4.6%。进一步以探空为真值,对FY-3E GNOS-II掩星产品在0~10 km对流层范围内进行比对校验,Transformer反演的温度和绝对湿度RMSE较掩星产品分别改善61.1%和71.3%。该方法兼具微波辐射计的高时间分辨率与接近探空的反演精度,可作为连接稀疏探空与连续卫星观测的桥梁,为风云卫星边界层产品提供动态验证基准,支撑卫星反演算法优化和地基–卫星协同观测体系的发展。
-
关键词:
- Transformer /
- 温湿廓线反演 /
- 自注意力机制 /
- 风云卫星 /
- GNOS
Abstract: Atmospheric temperature and humidity profiles are critical input parameters for satellite remote sensing retrieval, numerical weather prediction, and climate model simulations. The GNOS occultation detector onboard the Fengyun series satellites has achieved continuous global observation of atmospheric parameters, providing important data support for weather forecasting and extreme weather monitoring. However, the detection accuracy in the near-surface boundary layer is affected by underlying surface conditions and needs improvement. Radiosonde observations have high accuracy but limited temporal resolution with only twice-daily measurements, making it difficult to support continuous satellite validation. Ground-based microwave radiometers achieve continuous retrieval of temperature and humidity profiles by receiving atmospheric downwelling radiation brightness temperature, without underlying surface limitations, providing an important approach for satellite data comparison and validation. However, traditional retrieval methods have limited accuracy in the boundary layer. This paper presents an improved Transformer design for atmospheric retrieval tasks. Using radiosonde measurements from the Beijing South Suburban Observatory from 2020 to 2025 and MonoRTM radiative transfer model forward simulations to construct training datasets, a ground-based retrieval model based on the self-attention mechanism was established and compared with linear regression and BP neural networks. Results show that the Transformer retrieval accuracy is significantly improved compared to linear regression and BP neural networks, with temperature RMSE reduced by 29.7% and 10.1% respectively, and absolute humidity RMSE reduced by 26.8% and 4.6% respectively. Further comparison and validation of the FY-3E GNOS-II occultation product in the 0-10 km troposphere using radiosonde as truth show that the Transformer retrieval temperature and absolute humidity RMSE are improved by 61.1% and 71.3% respectively compared to the occultation product. This method combines the high temporal resolution of microwave radiometers with retrieval accuracy approaching that of radiosondes, serving as a bridge between sparse radiosonde and continuous satellite observations, providing dynamic validation benchmarks for Fengyun satellite boundary layer products, and supporting the development of satellite retrieval algorithm optimization and ground-satellite collaborative observation systems.
-
-
