DONG Enqiang, CAO Yueling, GONG Lei, LIU Xiaoping, CHANG Zhiqiao, WU Xiaoli. Real-time Monitoring Regional Ionospheric Variety of China with BDS Observations[J]. Chinese Journal of Space Science, 2017, 37(1): 67-74. doi: 10.11728/cjss2017.01.067
Citation: DONG Enqiang, CAO Yueling, GONG Lei, LIU Xiaoping, CHANG Zhiqiao, WU Xiaoli. Real-time Monitoring Regional Ionospheric Variety of China with BDS Observations[J]. Chinese Journal of Space Science, 2017, 37(1): 67-74. doi: 10.11728/cjss2017.01.067

Real-time Monitoring Regional Ionospheric Variety of China with BDS Observations

doi: 10.11728/cjss2017.01.067 cstr: 32142.14.cjss2017.01.067
  • Received Date: 2015-12-16
  • Rev Recd Date: 2016-06-04
  • Publish Date: 2017-01-15
  • BDS provides uninterrupted PNT service for Asia-Pacific area since 27 December 2012, when China released an official version of the complete BDS Interface Control Document (ICD) for open service Signal-In-Space (SIS). Because BDS signals working at three frequencies, ionospheric delay can be calculated with pseudo-range dual-frequency combination technique and a new technique to monitor ionospheric variety over China is established. Lower-middle latitude area of China is in the ionospheric equator anomalies region and large grads ionospheric varieties often occur within the area of north latitude 20°±5°. Daily variety characteristic of ionospheric delay measured with BDS GEO satellites is analyzed by using BDS real-time pseudo-range observation and adopting carrier phase smoothed pseudo-range. China region ionospheric map is painted in 1°×1° scale with polyhedral fitting every 5 minutes and the average fitting error RMS of all Ionospheric Punch Point (IPPs) is 2.778TECU. The ionospheric anomalies around China monitored with BDS observation shows that the VTEC peak difference between adjacent two days can be 60TECU when large scale ionospheric anomaly occurs.



  • loading
  • [1]
    RATCLIFFE J A. Ionosphere Disquisition for Fifty Years[M]. Beijing:Science Press, 1983(拉特克利夫J A. 电离层研究五十年[M]. 北京:科学出版社, 1983)
    [2]
    LIN Jian. GPS Ionospheric Observation Techniques and Its Application in Earthquake[D]. Wuhan:Wuhan University, 2011(林剑. GPS电离层观测技术及其在地震中的应用研究[D]. 武汉:武汉大学, 2011)
    [3]
    ZHANG Hongping. Study on GPS Based China Regio-nal Ionosphere Monitoring and Ionosphere Delay Correction[D]. Shanghai:Shanghai Astronomical Observatory, Chinese Academy of Sciences, 2006(章红平. 基于地基GPS的中国区域电离层监测与延迟改正研究[D]. 上海:中科院上海天文台, 2006)
    [4]
    China Satellite Navigation Office. Beidou Navigation Satellite System Signal In Space Interface Control Do-cument Open Service Signal B1I (Version 1.0)[M]. 北京:中国卫星导航系统管理办公室, 2012(中国卫星导航系统管理办公室, 北斗卫星导航系统空间信号接口控制文件公开服务信号B1I (1.0版)[M]. Beijing:China Satellite Navigation Office, 2012)
    [5]
    LIU Jingnan. Principles and Methods of Wide Area Differential GPS[M]. Wuhan:Surveying and Mapping Press. 1999(刘经南. 广域差分GPS原理和方法[M]. 武汉:测绘出版社, 1999)
    [6]
    WU Xiaoli, HAN Chunhao, PING Jinsong. Monitoring and analysis of regional ionosphere with GEO satellite observations[J]. Acta Geodaet. Cartog. Sin., 2013, 42 (1):13-18(吴晓莉, 韩春好, 平劲松. GEO卫星区域电离层监测分析[J]. 测绘学报, 2013, 42(1):13-18)
    [7]
    DONG Enqiang, SUN Weijie, WU Xiaoli, et al. Application of Curve Surface Fitting in Regional Ionospheric Delay Model with Sparse Station Distribution[C]//China Satellite Navigation Conference (CSNC)Proceedings, Lecture Notes in Electrical Engineering 244. Berlin:Springer, 2013:357-366
    [8]
    LIU Dajie, TAO Benzao. Process Methods of Practicality Observation[M]. Beijing, Mapping Express, 2000(刘大杰, 陶本藻. 实用测量数据处理方法[M]. 北京:测绘出版社, 2000)
    [9]
    CHANG Yifeng, CHAI Hongzhou, WANG Min. Study on construction of local marine geomagneti field model based on orthogonal least square multi-surface function[J]. J. Geod. Geodyn., 2012, 32(3):86-89(常宜峰, 柴洪洲, 王敏. 基于正交最小二乘多面函数构建局域海洋地磁场模型研究[J]. 大地测量与地球动力学, 2012, 32(3):86-89)
    [10]
    XIONG Nianlu, TANG Cunchen, LI Xingjian. An Introduction to Ionospheric Physics[M]. Wuhan:Wuhan University Press, 1995(熊年禄, 唐存琛, 李行健. 电离层物理概论[M]. 武汉:武汉大学出版社, 1999)
